Connecting to the RS-232C Port at the Host
74
Check the required components and prepare them in advance.
Name
Connector XM2A-0901
XM24-2501
DB-25P
Connector XM2S-0911
hood
XM2S-0913
XM2S-0911-E
XM2S-2511
DB-C2-J9
Cable AWG28×5P
IFVV-SB
CO-MA-VV-SB
5P×28AWG
Note After connecting a communications cable, always secure it with the screws.
OMRON Cables with Connectors
When a connection is made at serial port A in other than the memory link
method, OMRON cables with connectors shown below are available.
Model
XW2Z-200S
XW2Z-500S
XW2Z-200T
XW2Z-500T
Model Remarks
9-pin
Made by OMRON
25-pin
Made by OMRON
25-pin
Made by JAE
9-pin
Made by OMRON
9-pin
Made by OMRON
9-pin
Made by OMRON
25-pin
Made by OMRON
25-pin
Made by JAE
Multi-core shielded cable
Made by Fujikura, Ltd.
Multi-core shielded cable
Made by Hitachi Cable,
Ltd.
Cable Length
9-pin ⇔ 25 pin
2 m
5 m
9-pin ⇔ 9-pin
2 m
5 m
Section 4-1
Delivered with
CS-series CS1G/CS1H/
CS1D,
CJ-series CJ1G/CJ1H/
CJ1M,
C-series CQM1,
C200HS,
C200HX/HG/HE(-Z)E,
CVM1/CV-series CPU
Units
CV500-LK201
C500-LK203
CV500-LK201
C200H-LK201-EV1
3G2A5-LK201-EV1
3G2A6-LK201-EV1
C-series CQM1,
C200HS,
C200HX/HG/HE(-Z)E,
CVM1/CV-series CPU
Units
CV500-LK201
CS-series CS1G/CS1H/
CS1D,
CJ-series CJ1G/CJ1H/
CJ1M
C500-LK203
CV500-LK201
C200H-LK201-EV1
3G2A5-LK201-EV1
3G2A6-LK201-EV1
Connector Specification
