Setting Item
Display of Lamp/ Allows designation of whether the bit number of the lamp bit set for a lamp or touch
Touch SW No. switch is displayed or not.
The display format is as follows L@❍❍❍❍❍❍❍ (@: area type, ❍❍❍❍❍❍❍: bit num-
ber).
Display of Memory Allows designation of whether the table numbers of numeral and character string
Table No. memory tables are displayed or not.
The display format for numeral memory tables is N❍❍❍❍ and the display format for
character string memory tables is S❍❍❍❍.
This function is valid for the following display elements.
- Numeral displays
- Character string displays
- Bar graphs
- Numeral setting input fields (including thumbwheel type)
- Character string input fields
Display of image/ Allows designation of whether image/library code numbers are displayed or not.
Library No.
Display of Broken Allows designation of whether or not broken line frames are displayed around the dis-
Line Frame play elements for showing the positions registered.
* Default (factory) setting
Reference:
Specifying The Display Method
Specify the display method for the screens as indicated in the table below.
Function
Each setting of the screen data check is effective only on this menu. Exiting
from this screen data check menu resets the settings to the default (all the
settings are set to OFF).
Operations On The SCREEN DATA CHECK Screen
The function shown below can be set on the SCREEN DATA CHECK screen.
Use this function as required when displaying complex screens on which mul-
tiple display elements have been registered overlapping each other.
a. Display the previous display element on the upper most portion of the
screen in the order in which the display elements were registered (ex-
cluding fixed display elements).
b. Display the next display element on the upper most portion of the
screen in the order in which the display elements were registered (ex-
cluding fixed display elements).
c. Return to the screen on which screens are specified.
a) Equivalent to 2 touch switches (14.4 mm)
NT631
NT631C : 13.2 mm
c)
b) Equivalent to 2 touch switches (14.4 mm)
NT631
NT631C : 13.2 mm
Section 6-11
Setting
Options
ON, OFF*
ON, OFF*
ON, OFF*
ON, OFF*
: 14.4 mm
: 14.4 mm
