Programming Environment; Special Features - Omron Programmable Terminals NT631 Setup Manual

Specifications

Programming Environment

Item
Programming System Programming support software
Programming Tool Programming support software
NT-series Support Tool for Windows (Ver. 4.@), made by OMRON

Special Features

Item
Buzzer
Touch switch input sound
Maintenance function
Battery backup
Resume function
Screen print function
Calendar and clock function
Three kinds of buzzer sound (continuous, short intermittent, and long intermittent)
ON: On reception of a command from the host, display of a screen with a buzzer
setting, or display of an error screen such as for a receive error.
OFF: On reception of a command from the host, or display of a screen with no
buzzer setting.
Setting: Set "ON" for "Buzzer Sound" in the memory switch menu, or set "ERROR
ON" for the buzzer to sound only when an error occurs.
The buzzer sounds three times in response to prohibited input.
Touch switches
Input sound: Sounding for 0.2 seconds
Setting: Set "ON" for "Key Press Sound" in the memory switch menu.
- Memory switch setting
- Self-test functions, such as for the memory and external interface
- Setting condition confirmation function
- Communications check function
- Initialization of internal memory data
- Display of display/alarm history data
- Registered data test display function
- Backup of numeral/character string memory table data in the NT631/NT631C
- Backup of display/alarm history data
- Backup of calendar and clock setting
Battery life:
When voltage becomes low:
Retains the contents of the numeral/character string memory tables (i.e., they are not
initialized) when the power is turned ON, when the NT631/NT631C is reset, and when
the operation mode is changed.
Setting: Set "ON" for "Resume Function" in the memory switch menu.
Functions: - Prints a hard copy of the screen display
- Prints display/alarm histories
Setting: Set the printing protocol ("Print Controller") and printing type ("Print
Method") in the memory switch menu.
"ESC/P", "Color":
"PC-PR201H", "Color":
"ESC/P", "Tone":
"PC-PR201H", "Tone":
"PCL 5", "Tone":
However, the NT631 supports monochrome printing only.
- Displays the current time in accordance with the built-in clock
- Displayed and set with "Calendar Check" in the "MAINTENANCE MODE" menu
Specification
Specifications
5 years (at 25°C)
RUN LED lights in orange or red
The communications flag to the PLC (BAT LOW)
comes ON (1).
Color printing conforming to ESC/P 24-J83C
Color printing conforming to PC-PR201PL
Monochrome printing in 8 grayscale levels,
conforming to ESC/P 24-J82
Monochrome printing in 8 grayscale levels,
conforming to PC-PR201PL
Monochrome printing in 8 grayscale levels,
conforming to PCL 5
Appendix A
249
