Connecting to the Host's RS-422A/485 Port
PLC CPU Unit with built-in Host
Series Link
CS Series
CJ Series
C Series
CPM1-10/20/30CDR-@
+CPM1-CIF11
CPM1A-10/20/30/40CD@-@
+CPM1-CIF11
CPM2A-30/40/60CD@@-@
+CPM1-CIF11
(Peripheral port connection)
CPM2C-10/20@@@@@@-@
The hosts featuring the RS-422A/485 host link function and can be connected
to the RS-422A/485 port of the NT631/NT631C are indicated in the table
below.
CPU Units Connectable with
Host Link Units or
Expansion Communications
Board/Units
CS1G-CPU42/43/44/45-E(V1)
CS1H-CPU63/64/65/66/67-
E(V1)
CS1G-CPU42H/43H/44H/45H
CS1H-CPU63H/64H/65H/66H/
67H
CS1D-CPU65H/67H
CJ1G-CPU44/45
CJ1G-CPU42H/43H/44H/45H
CJ1H-CPU65H/66H/67H
CJ1M-CPU11/12/13/21/22/23
C1000H-CPU01-EV1
C2000H-CPU01-EV1
C200HS-CPU01/03/21/23/31/
33-E
C200HS-CPU01/21-EC
C200HE-CPU11/32/42-E
C200HE-CPU11/32/42-ZE
C200HG-CPU33/43/53/63-E
C200HG-CPU33/43/53/63-ZE
C200HX-CPU34/44/54/64-E
C200HX-CPU34/44/54/64/65/
85-ZE
C200HE-CPU32/42-E
C200HE-CPU32/42-ZE
C200HG-CPU33/43/53/63-E
C200HG-CPU33/43/53/63-ZE
C200HX-CPU34/44/54/64-E
C200HX-CPU34/44/54/64/65/
85-ZE
C1000H-CPU01-EV1
C2000H-CPU01-EV1
C1000H-CPU01-EV1
C2000H-CPU01-EV1
(*2)
CQM1H-CPU51/61
Host Link Unit or
Communications Board/
Unit
CS1W-SCB41(-V1)
CS1W-SCU31(-V1)
(*1)
CJ1W-SCU31(-V1)
CJ1W-SCU41(-V1)
3G2A6-LK202-EV1
C200H-LK202-V1
C200HW-COM03/06-EV1
3G2A5-LK201-EV1
C500-LK203
CQM1H-SCB41
Section 5-2
Connectable
to
CS1G
CS1H
CS1D
CJ1G
CJ1H
CJ1M
C1000H
C2000H
C200HS
C200HE
C200HE-ZE
C200HG
C200HG-ZE
C200HX
C200HX-ZE
C200HE
C200HE-ZE
C200HG
C200HG-ZE
C200HX
C200HX-ZE
C1000H
C2000H
C1000H
C2000H
CPM1
CPM2A
CPM2C
CQM1H
95
