Chapter 7 — Transfer Ribbon Mechanism
7.1 Description
50
Downloaded from
www.Manualslib.com
The thermal transfer ribbon mechanism is standard in EasyCoder PX4i
and PX6i. The mechanism consists of three main parts:
• Ribbon supply unit (see Chapter 7.2)
• Ribbon rewind unit (see Chapter 7.3)
• Ribbon sensor (see Chapter 7.4)
Adjustment of the ribbon assist roller to remedy wrinkling of the ribbon is
described in Chapter 8.9.
manuals search engine
Ribbon Rewind Unit
Ribbon Supply Unit
EasyCoder PX4i and PX6i Service Manual
Ribbon Sensor
