Intermec EasyCoder PX4i Service Manual page 187

Remove strap on J2 A
Remove RS-232 circuit
on IC11
Fit RS-485 driver circuit
Fit strap on J4
if end of cable
(terminator)
Fit strap on J1
-DATA
EasyCoder PX4i and PX6i Service Manual
Downloaded from www.Manualslib.com
RS-485 Isolated, Half Duplex (reconfiguration required)
RS232: IC11, J2A
RS422: IC12, J3, J4
RS485: IC13, J1, J4*
* IF END OF CABLE
UARTA
Connector Configuration
(RS-485 Isolated on "uart2:" only)
DB-9 socket
MTG
1
5
GNDE
9
4
8
2
3
7
3
2
+DATA
6
+5V DC
1
4
if GND
5
strap fitted
MTG 6
7
8
9
Note: The increased use of LAN networks has made the RS-485 interface
somewhat obsolete, because RS-485 requires a special communication
protocol and a dedicated wiring system limited to 1,200 m (4,000 ft). We
only recommend RS-485 for existing applications and advice the customer
to consider a LAN network solution for new applications.
manuals search engine
REL4
REL3
REL2
REL1
C3
C4
R14
C2 C1
B A IC13
J2
R13
IC11 IC12
R15
R8
R12 R18
J3
R10
C56
R9
C57
C54
P2
Signal Meaning
External +5VDC max 500 mA (automatic switch-off at
overload, short-circuit protected) provided strap is fi tted
on J2:A which spoils the galvanical isolation
+DATA
–
–
GNDE Ground
–
–
-DATA
–
Chapter 16 — Interfaces
R31
R32
R33
R34
R35
R36
R37
R38
C60
R27
R26
R25
R24
R23
R22
R21
C61
C51
C67
C34
C36
IC3
C66
P1
C33
C35
IC10
C50
J1
