Chapter 8 — Print Unit
Stepper motor
Pulleys
Platen roller
(barely visible)
Tear bar
62
Downloaded from
www.Manualslib.com
EasyCoder PX4i
The parts of the EasyCoder PX4i print unit, as seen from the media
compartment side of the center section, are illustrated below. Cables are
excluded.
Belt to ribbon
rewind unit
Liner drive roller
Printhead with
bracket
manuals search engine
Pressure arm
Printhead
position
adjustment
Printhead
pressure
adjustment
Printhead lift
lever
Edge guide
LSS adjustment screw
EasyCoder PX4i and PX6i Service Manual
