16
This chapter describes the various communication interfaces for the Easy-
Coder PX4i and PX6i printers. However, some interfaces are not sup-
ported by the Intermec Programming Language (IPL) even though the
connectors are present.
The chapter describes three categories:
• Standard built-in interfaces
RS-232 interface
USB interface
Bar code wand interface (Fingerprint only)
• Optional interface boards
Serial/Industrial interface board (Fingerprint only)
Double Serial interface board (Fingerprint only)
IEEE 1284 Parallel interface board
• EasyLAN interface boards
EasyLAN Ethernet interface
EasyLAN Wireless interface
The EasyCoder PX4i and PX6i can—in addition to the standard built-in
interfaces—also be fi tted with one or two optional interface boards and
one EasyLAN interface board.
Note: Device designations, such as "uart1:", "usb1:", or "net1:", only
apply to Fingerprint, not to IPL.
