Chapter 8 — Print Unit
Stepper motor
#T20 Torx
screw
Belt to platen roller
68
Downloaded from
www.Manualslib.com
EasyCoder PX4i
In the illustration below, the upper parts of the print unit and the label
stop sensor have been removed to improve visibility.
#T20 Torx screw
Pulley
Ball bearing
Plastic bearing
Spacer
manuals search engine
Belt to ribbon
rewind unit
Platen roller
Spacer
Plastic bearing
Ball bearing
#T20 Torx screw
EasyCoder PX4i and PX6i Service Manual
Bracket
