Hinges
(front door
or cutter)
EasyCoder PX4i and PX6i Service Manual
Downloaded from
www.Manualslib.com
The main differences between the chassis of EasyCoder PX4i and PX6i are
the widths of the bottom plate and the rear plate.
Center section
Rubber foot (x4)
manuals search engine
Bottom plate
EasyCoder PX6i
Chapter 4 — Chassis
Rear plate
Hinges
(right-hand door)
31
