Stepper motor
Pulleys
Platen roller
Tear bar
EasyCoder PX4i and PX6i Service Manual
Downloaded from
www.Manualslib.com
EasyCoder PX6i
The parts of the EasyCoder PX6i print unit, as seen from the media
compartment side of the center section, are illustrated below. Cables are
excluded.
Belt to ribbon
rewind unit
Liner drive roller
Printhead with
bracket
manuals search engine
Chapter 8 — Print Unit
Pressure arm
Printhead
position
adjustment
Printhead
pressure
adjustment
Printhead
lift lever
Edge
guide
LSS adjustment
screw
63
