Chapter 9 — Liner Takeup Kit
EasyCoder PX6i
Flange
Spring
Brake sleeve
112
Downloaded from
www.Manualslib.com
Snap ring
Pulley
Bearing
Snap ring
Shaft
Spring brake assy.
manuals search engine
Bearing
Flange
Snap ring
Bearing
Bearing
#T10 Torx
screws (x2)
Pin
EasyCoder PX4i and PX6i Service Manual
Bobbin gable
Bobbin
plate
Bobbin
Bearing
