Intermec EasyCoder PX4i Service Manual page 21

Chapter 1 — Models and Options
Power Supply
AC Voltage
PFC Regulation
Power Consumption
Sensors
Label Gap/Black Mark/Out of Media
Printhead Lifted
Ribbon End/Ribbon Low
Paper Sensor
Controls
Indicator Lamps
Display
Keyboard (Fingerprint)
Keyboard (IPL)
Print (FP) or Feed/Pause (IPL) button
Beeper
Data Interfaces
Serial
Bar Code Wand
Connection for Optional Interface Boards
Cutter Interface
Memory Card Adapter
Accessories and Options
Integral Self-strip Unit with Liner Takeup
Fan-fold Guide
Cutter
Label Taken Sensor
Real Time Clock
RS-232 Cable
Parallel Interface Cable
Parallel Interface Board
Double Serial Interface Board
Serial/Industrial Interface Board
EasyLAN Ethernet Interface
EasyLAN Wireless Interface
Built-in Alphanumeric Keyboard
External Keyboard Converter
CompactFlash Cards
CompactFlash Protection Plate
1 /. The max. print length is also restricted by the amount of free SDRAM memory.
2 /. Latin, Greek, and Cyrillic fonts according to Unicode standard are included.
3 /. Factory installed option
4 /. Field-installable kit. Installation should be performed by a service technician.
5 /. Operator-installable option.
EasyCoder PX4i and PX6i Service Manual
Downloaded from www.Manualslib.com manuals search engine
90 to 265 VAC, 45 to 65 Hz
IEC 61000-3-2
Standby 20W; Continuous, average 175W;
Peak 400W
Yes
Yes
Yes
Yes
3
2 x 16 character LCD
22 keys membrane-switch type
7 keys membrane-switch type
1
Yes
1 x RS-232 + 1 x USB
Yes
1 EasyLAN + 2 other (Fingerprint/DP)
1
1, for CompactFlash cards
Option 3,4
5
Option
Option 5
Option 3,4
3,4
Option
Option
Option
Option
Option 3,4
Option 3,4
3,4
Option
Option 3,4
3,4
Option
Option 5
Option 5
5
Option
Variable position
Background light
Not supported by IPL
IPL: 1 other + 1 EasyLAN
IPL: Not as memory
For peel-off operation
Not supported by IPL
Not supported by IPL
Not supported by IPL
Not supported by IPL
8MB-1GB
11
