The parameters sectors store the PFSVARs (see SETPFSVAR Fingerprint
statement), odometer values, and a few other "invisible" fi les with data,
that are required for the printer to start up with the same settings as when
it was shut off, for example information on the position of label gaps in
relation to the LSS.
The printer's permanent memory can be expanded by fi tting a second
4MB or 8MB fl ash memory SIMMs in sockets J21. 4MB and 8MB fl ash
SIMMs can be mixed at will. Flash SIMMs are custom-made and can only
be ordered from Intermec.
Note: The fi rst time the printer is started with a SIMM in J21 ("EXP
FLASH"), the memory is not increased to enable cloning the fi rst SIMM.
The expansion is not done until the second time the printer is started.
Flash Memory Available to the User
J20 (Boot)
4MB SIMM
4MB SIMM
4MB SIMM
8MB SIMM
8MB SIMM
8MB SIMM
manuals search engine
J21 (Exp) J20 (Boot)
– 1.8MB
4MB SIMM 1.8MB
8MB SIMM 1.8MB
– 5.8MB
4MB SIMM 5.8MB
8MB SIMM 5.8MB
Chapter 15 — CPU Board
J21 (Exp) SUM
– 1.8MB
4MB 5.8MB
8MB 9.8MB
– 5.8MB
4MB 9.8MB
13.8MB
8MB
