16.10 EasyLAN Wireless Interface Board

Description
Printer Firmware
Installation Kit
EasyCoder PX4i and PX6i Service Manual
Downloaded from www.Manualslib.com
This section describes how to install an EasyLAN Wireless network inter-
face in an EasyCoder PX4i and PX6i printer and how to connect it to a
LAN, WAN, Intranet, or Internet network via a wireless connection.
The installation instructions describes how to physically install the inter-
face board in a printer. Confi guration and setup are described in the
EasyLAN Wireless Kit, Installation Instructions and the Intermec EasyLAN,
User's Guide on the attached CD-ROM.
This interface kit must only be physically installed by an authorized
service technician. The device is country/region specifi c and must be
ordered for the correct country/region. Use of this device in other region
than shown on the device home page/test label may violate applicable
law.
The printer must either be fi tted with Intermec Fingerprint v8.30 (or
later) or IPL v2.30 (or later). In Intermec Fingerprint, the network port is
addressed as device "net1:" (communication channel #5).
The EasyLAN Interface Kit contains:
• One EasyLAN adapter board complete with radio module fi tted
• Rear plate (for EasyCoder PF2/4i-series printers only)
• RJ-45 plug (for EasyCoder PM4i, PX4i, and PX6i only)
• One light guide
• One hexagonal threaded spacer
• One antenna extension cable
• One antenna
• One cable clip
• One cable tie
• One CD-ROM with software and manuals
• One Installation Instruction booklet
The only tools required for the installation are #T10 and #T20 Torx screw-
drivers and a small wrench.
