Chapter 8 — Print Unit
66
Downloaded from
www.Manualslib.com
The parts of the print mechanism fi tted inside the electronics compart-
ment in an EasyCoder PX4i printer are illustrated below.
Idle roller
Stepper motor
(liner takeup)
manuals search engine
CPU board
Pulley & belt
(platen roller)
Stepper motor
(platen roller & ribbon
rewind unit)
EasyCoder PX4i and PX6i Service Manual
Driver board
Ribbon
rewind unit
Pulley & belt
(liner drive
roller)
