8.2.8 Deleting saved Route
The Delete command allows you to delete routes that you no longer need from
the route list. When you choose this command, ECDIS displays the Delete Route
dialog box, which contains a list of all the routes you have saved. You can delete
as many routes as you want before closing the dialog box. Once a route is
deleted, it cannot be retrieved.
Procedure: (see Figure: 1−24)
Step 1 Select Open Route from the Routes menu..
Step 2 Click on the name of the route you want to delete.
3655DOC020102
Operator Manual
Select Delete Route. The Delete Route dialog box appears displaying
the names of all the routes stored in the route list.
Click on Delete. ECDIS deletes the route from the route list and the
list box. The dialog box remains open for you to delete additional
routes.
Click on Quit when you are done.
Figure: 1−24 Delete Route dialog box
