• The WindoWall Pro sends a
configured via the new connection.
Reconfig
Reconfig
Reconfig
Reconfig
• The WindoWall Pro sends the output and input numbers response when an input is
switched.
Out n In nn

Error Responses

When the WindoWall Pro receives a valid SIS command, it executes the command and
sends a response to the host device. If the processor is unable to execute the command
because the command is invalid or contains invalid parameters, it returns an error response
to the host. The error response codes are:
— Invalid input channel number (too large)
E01
— Invalid function number (too large)
E09
— Invalid command
E10
— Invalid preset number
E11
— Invalid output number (applies for addressing windows)
E12
— Invalid value (out of range)
E13
— Invalid for this configuration
E14
— Invalid command for signal type
E17
— Privilege violation
E24
— Maximum number of users connected has been exceeded
E26
— Invalid event number
E27
— Bad filename/File not found
E28

Telnet and Web Communications

The WindoWall Pro can also be controlled via an IP connection using either Telnet (port 23)
or a web browser (port 80). The ASCII and URL commands listed in the tables in this panel
perform the same functions but are encoded differently to accommodate the requirements
of each port (Telnet or browser).
The ASCII to hexadecimal (hex) character conversion table below is for use with the
command and response table (see
SIS Commands
Space
Figure 31.
Reconfig
is the window number and
Out n
Command and Response Table for WindoWall Pro
beginning on page 37).
ASCII to Hex Conversion Table
ASCII to Hexadecimal Character Conversion Table
WindoWall Pro Series • Remote Configuration and Control
message as each of the four windows is
is the input number.
In nn
•
