4. Press the <Enter> key. If the WindoWall Pro HTML pages are not password protected,
the browser displays a start page as described in step 5.
If the WindoWall Pro HTML pages are password protected, the browser displays the
Connect To dialog box.
Figure 32. Example of a Connect To Dialog Box
a. Enter the administrator or user password in the
NOTE: A User Name entry is not required.
b. If desired, select the
your password the next time you enter the IP address.
c.
Click .
OK
5. If you entered the filename for a custom HTML page in step 4, the browser displays that
page. If not, the browser displays the System Status page, which is the WindoWall Pro
default start page. You can select the tabs at the top of this screen to display additional
screens that enable you to configure the WindoWall Pro.
check box to have the system input
Remember my password
WindoWall Pro Series • HTML Configuration and Control
field.
Password
52
