Extron electronics WindoWall Pro Series User Manual page 26

Input Source Icons
DVD player
Laptop PC
MAC computer
Desktop PC
Security camera
Workstation PC
VCR
Video conferencing
c. From the
Video Format
d. Select the
Dynamic Input
might vary (for example, in the case of a laptop input source, different laptops with
different resolutions might be connected to the system).
e. From the
Aspect Ratio
input source will have when it is added to the configuration. This source aspect ratio
can subsequently be changed if desired.
f. Select the
Lock Aspect Ratio
aspect ratio cannot be changed after the input has been added to the project.
When the aspect ratio is locked, the window can still be resized.
g. When finished setting up the first input, click
name of the first source are displayed in the source list field to the right, categorized
by signal type.
h. Repeat steps a through f for the rest of your input sources.
To make changes to a source — If you want to make changes at any time to an input
listed in the source panel, select the input icon. Its parameters are displayed in the fields
to the left. Make any desired changes in those fields, then click
To delete a source — To remove a source from the list, select its name/icon, then click
.
Delete
Click when finished setting up input sources.
Next
Figure 18 on the previous page shows a set of sources that have been added to a
configuration.
WindoWall Pro Series • Remote Configuration and Control
Cable feed
Camera
Map (PC)
Media server
Satellite
TIVO
Test generator
TV broadcast
drop-down menu, select the format for your first source.
check box if the source input resolution is unknown or
drop-down menu, select the default aspect ratio that the
check box if you want to specify that the window
. The selected source icon and the
Add
.
Apply Changes
20
