Special Application:
Edge Blending
This section describes examples of applications using edge blending and edge matching.
It also provides instructions for setting up an edge blending application using the Setup
Wizard. Topics include:
•
•
•

Example of a System Using Edge Blending

In an edge-blended system, projectors with edge blending functionality are used to display
multiple images on one screen to form a videowall display that appears to be one image.
Figure 42 shows a diagram of a typical edge-blended system.
Source #1
Source #2
Source #3
Source #4
Source #5
Source #6
Source #7
Source #8
...
Source #128
Figure 42.
Example of a System Using Edge Blending
Example of an Edge-matched System
Setting Up the WindoWall Console Software for Edge Blending
1
2
3
4
Crosspoint
450+
Matrix
Switcher
5
6
7
8
9
10
11
12
Typical Edge-blended System
WindoWall Pro Series • Special Application: Edge Blending
MGP 464W
Projector
MGP 464W
Projector
MGP 464W
Projector
64
