21 - 4 TRANSMISSION AND TRANSFER CASE
SPECIFICATIONS (Continued)
Fig. 6 Clutch Housing to Transmission
1 – TRANSMISSION
2 – CLUTCH HOUSING
3 – CLUTCH HOUSING BOLT
4 – RELEASE BEARING
5 – RELEASE FORK
6 – PIVOT
Fig. 7 Fill Plug Location
1 – GEAR CASE
2 – FILL PLUG
2000 JEEP CHEROKEE
SPECIFICATIONS
TORQUE
DESCRIPTION
Clutch Housing to Engine Top (2) Bolts . . 36.6 N·m
Clutch Housing to Engine Mid-Point
(2) Bolts . . . . . . . . . . . . . . . 58.3 N·m (43 ft. lbs.)
Clutch Housing to Engine Bottom
(2) Bolts . . . . . . . . . . . . . . . 74.6 N·m (55 ft. lbs.)
Clutch Housing to Transmission bolts . . . 38.0 N·m
Transfer Case to Transmission
Attaching Nuts . . . . . . . . . . . 35 N·m (26 ft. lbs.)
Propeller Shaft Bolts . . . . . . 26.5 N·m (19.5 ft. lbs.)
XJ
TORQUE
(27 ft. lbs.)
(28 ft. lbs.)
