SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 4 CONTENTS Introduction ......4 Rollover Warning ......5 How To Use This Manual .
Page 5: Introduction
4 INTRODUCTION INTRODUCTION This is a specialized utility vehicle designed for both on-road and off-road use. It can go places and perform tasks for which conventional two-wheel drive enclosed vehicles were not intended. It handles and maneuvers differently from many passenger cars both on-road and off-road, so take time to become familiar with your vehicle.
Page 6: Rollover Warning
NOTE: After you read the manual, it should be stored in the vehicle for convenient reference and remain with the vehicle when sold so that the new owner will be aware of all safety warnings. When it comes to service, remember that your authorized dealer knows your vehicle best, has the factory-trained technicians and genuine MOPAR parts, and is inter- ested in your satisfaction.
Page 7: How To Use This Manual
6 INTRODUCTION Do not attempt sharp turns or abrupt maneuvers or other unsafe driving actions that can cause loss of vehicle control. Failure to operate this vehicle safely may result in an accident, rollover of the vehicle and serious injury or death.
Page 8 INTRODUCTION 7...
Page 9: Warnings And Cautions
8 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in an accident or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.
Page 10: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Ignition Key Removal ....12 Key-In-Ignition Reminder .
Page 11 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Turn Off “Flash Lights With Lock” ..21 Programming Additional Transmitters ..22 General Information ....23 Battery Replacement .
Page 12 Seat Belt Pretensioners ....48 Enhanced Seat Belt Use Reminder System (BeltAlert ) ......49 Seat Belts And Pregnant Women .
Page 13: A Word About Your Keys
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The keys for your new vehicle are enclosed in a plastic bag with the key code number on it. If you received your keys without the bag, ask your authorized dealer to give you the number.
Page 14 Automatic Transmission — If Equipped 1. Place the shift lever in the PARK position. 2. Turn the ignition switch to the ACC position. Ignition Key Positions 3. Push the ignition key inward. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 4.
Page 15: Key-In-Ignition Reminder
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Key-In-Ignition Reminder Opening the driver’s door when the key is in the ignition, sounds a signal to remind you to remove the key. STEERING WHEEL LOCK Your vehicle is equipped with a passive steering wheel lock.
Page 16 the vehicle. The system will shut the engine off in two seconds if someone uses an invalid key to try to start the engine. NOTE: A key that has not been programmed is also considered an invalid key, even if it is cut to fit the ignition switch lock cylinder for that vehicle.
Page 17: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Replacement Keys NOTE: Only keys that are programmed to the vehicle electronics can be used to start and operate the vehicle. Once a Sentry Key is programmed to a vehicle, it cannot be programmed to any other vehicle.
Page 18: General Information
3. Insert the second valid key into the ignition switch. Turn the ignition switch to the ON position within 15 seconds. After 10 seconds, a chime will sound. In addi- tion, the Vehicle Security Alarm Indicator Light will begin to flash. Turn the ignition switch to the LOCK position and remove the second key.
Page 19: Security Alarm System - If Equipped
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • This device must accept any interference that may be received, including interference that may cause undes- ired operation. SECURITY ALARM SYSTEM — IF EQUIPPED This system monitors the vehicle doors, swing gate, and ignition for unauthorized operation.
Page 20: Illuminated Entry
The Security Alarm System is designed to protect your vehicle; however, you can create conditions where the system will arm unexpectedly. If you remain in the vehicle and lock the doors with the RKE transmitter, once the system is armed (after 16 seconds), when you pull the door handle to exit, the alarm will sound.
Page 21: To Unlock The Doors And Swing Gate
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The line of transmission must not be blocked with metal objects. To Unlock the Doors and Swing Gate Press and release the UNLOCK button once to unlock the driver’s door only, or twice to unlock all the doors and swing gate.
Page 22: Using The Panic Alarm
2. While the LOCK button is pressed (after four seconds), press the PANIC button. Release both buttons. The “Sound Horn On Lock” feature can be reactivated by repeating this procedure. Using The Panic Alarm To turn the panic alarm feature ON or OFF, press and hold the PANIC button on the key fob for at least one second and release.
Page 23: Programming Additional Transmitters
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Programming Additional Transmitters Vehicles will be shipped from the assembly plants with two key fob transmitters programmed only for that vehicle. A total of eight key fobs can be programmed for your vehicle. Additional key fobs can be programmed to your vehicle through the use of a currently programmed fob.
Page 24: General Information
11. A single chime will be heard. 12. Repeat steps 8 through 10 to program up to six additional key fobs. 13. Turn the ignition to the OFF position. 14. Your vehicle will remain in program mode up to 60 seconds from when the original chime was heard.
Page 25: Battery Replacement
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Battery Replacement The recommended replacement battery is CR2032. NOTE: Perchlorate Material – special handling may apply; www.dtsc.ca.gov/hazardouswaste/ perchlorate. 1. If the key fob is equipped with a screw, remove the screw. With the key fob buttons facing down, use a flat blade (screwdriver) to pry the two halves of the trans- mitter apart.
Page 26: Remote Starting System - If Equipped
NOTE: If the key fob is equipped with a screw, reinstall and tighten the screw until snug. REMOTE STARTING SYSTEM — IF EQUIPPED Your vehicle may be equipped with a remote starting system (automatic transmission models only), which will allow the vehicle to be started from distances up to approximately 300 ft (91 m) away from the vehicle using the remote keyless entry key fob which is part of your ignition key.
Page 27: Doors
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The park lamps will remain illuminated to indicate that the vehicle has remote started and the engine is running. The lamps will turn off when the ignition is turned to RUN or the remote start is cancelled. To enter the vehicle while the engine is running during a remote start, you must first unlock the vehicle using the UNLOCK button on the key fob.
Page 28: Upper Half Door Window Removal (If Equipped)
If any other active warnings including “gATE”, “gAS- CAP”, “noFUSE”, “CHANgE OIL”, or “ESPOFF” are present, they will be shown in the VF display and will also continue to cycle. If the vehicle is moving, three single chimes will occur, one chime for each complete display cycle (three cycles total).
Page 29: Front Door Removal
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Push down to ensure the half door window is fully seated. Front Door Removal 1. Remove the hinge pin screws from the upper and lower outside hinges (using a #T50 Torx head driver). 2.
Page 30: Rear Door Removal (Four-Door Models)
3. Unhook the door strap from the body hook. Be careful not to allow the door to swing fully open as the mirror may damage paint. 4. With the door open, lift the door to clear hinge pins from their hinges, and remove door. To reinstall the door(s), perform the previous steps in the opposite order.
Page 31 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Remove the trim access door from the bottom of B-pillar. 4. Unplug the wiring harness connector. 5. Unhook the door strap from the body hook. 6. With the door open, lift the door to clear hinge pins from their hinges, and remove door.
Page 32: Door Locks
DOOR LOCKS The vacuum fluorescent (VF) display located in the odometer area displays the word “door” as an indication of a door ajar or door not completely closed. When the vehicle is not moving and the door is ajar or not completely closed, the VF display will show the word “door.”...
Page 33: Manual Door Locks
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Manual Door Locks The front (two-door models) and rear doors (four-door models) are equipped with a rocker-type interior door lock. To lock the door when leaving your vehicle, press the Lock position and close the door. Manual Door Lock WARNING! •...
Page 34: Power Door Locks - If Equipped
Power Door Locks — If Equipped The door lock switch is located on each front door panel. Press the switch downward to lock the doors, and upward to unlock the doors. Power Door Lock Switch THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 WARNING! •...
Page 35: Automatic Unlock Doors On Exit
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Unlock Doors On Exit The doors will unlock automatically on vehicles with power door locks if: 1. The “Automatic Unlock Doors On Exit” feature is enabled 2. The transmission was in gear and the vehicle speed returned to 0 mph (0 km/h) 3.
Page 36: Automatic Door Locks
Automatic Door Locks The doors will lock automatically on vehicles with power door locks if all of the following conditions are met: 1. The “Automatic Door Locks” feature is enabled 2. The transmission is in gear 3. All doors are closed 4.
Page 37: Windows
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WINDOWS Power Windows — If Equipped The power window switches are located on the instru- ment panel center stack (below the radio). The top left switch controls the left front window and the top right switch controls the right front window.
Page 38: Rear Power Windows (Four-Door Models Only)
console. To disable the window controls, press the win- dow lockout button downward. To enable the window controls, press the window lockout button upward. Auto Down Both the driver and front passenger window switches have an “Auto Down” feature. Press the window switch past the first detent, release, and the window will go down automatically.
Page 39: Wind Buffeting
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down in certain open or partially open posi- tions.
Page 40 Gate Handle NOTE: Close the rear flip-up window before attempting to close the swing gate (hard top models only). THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 CAUTION! Do not press on rear wiper blade when closing the rear flip-up window, as damage to the blade will result.
Page 41: Occupant Restraints
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems. These include the front and rear seat belts for the driver and all passengers, front airbags for both the driver and front passenger, and side airbags (if equipped) for both the driver and front passenger.
Page 42: Lap/Shoulder Belts
Research has shown that seat belts save lives, and that they can reduce the seriousness of injuries in a collision. Some of the worst injuries happen when people are thrown from the vehicle. Seat belts reduce the possibility of ejection and the risk of injury caused by striking the inside of the vehicle.
Page 43 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Wearing a seat belt incorrectly is dangerous. Seat belts are designed to go around the large bones of your body. These are the strongest parts of your body and take the forces of a collision the best. Wearing your belt in the wrong place could make your injuries in a collision much worse.
Page 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Latch Plate Latch Plate To Buckle...
Page 45 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! A belt that is buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal injuries. Always buckle your belt into the buckle nearest you. A belt that is loose will not protect you as well.
Page 46 Removing Slack From Belt THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 WARNING! A lap belt worn too high can increase the risk of internal injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdomen.
Page 47: Rear Center Lap/Shoulder Belt Retractor Lock-Out (Four-Door Models Only)
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. The belt will automatically retract to its stowed position. If necessary, slide the latch plate down the webbing to allow the belt to retract fully. WARNING! A frayed or torn belt could rip apart in a collision and leave you with no protection.
Page 48: Adjustable Upper Shoulder Belt Anchorage
WARNING! The rear center lap/shoulder belt is equipped with a lock-out feature to ensure that the rear seatback is in the fully upright and locked position when occupied. If the rear seatback is not fully upright and locked and the rear center lap/shoulder belt can be pulled out of the retractor, the vehicle should immediately be taken to your authorized dealer for service.
Page 49: Seat Belt Pretensioners
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Position the shoulder belt height adjusters so that the belt rests across the middle of your shoulder. Failure to adjust the safety belt properly could reduce the effectiveness of the seat belt and increase the risk of injury in a collision.
Page 50: Enhanced Seat Belt Use Reminder System (Beltalert )
Enhanced Seat Belt Use Reminder System (BeltAlert ) If the driver’s seat belt has not been buckled within 60 seconds of starting the vehicle and if the vehicle speed is greater than 5 mph (8 km/h), the Enhanced Warning System (BeltAlert ) will alert the driver to buckle the seat belt.
Page 51: Seat Belts And Pregnant Women
50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Enhanced Warning System (BeltAlert ) can be reac- tivated by repeating this procedure. NOTE: Although the Enhanced Warning System (BeltAlert ) has been deactivated, the Seat Belt Warning Light will continue to illuminate while the driver’s seat belt remains unfastened.
Page 52: Driver And Front Passenger Supplemental Restraint Systems (Srs)
Driver And Front Passenger Supplemental Restraint Systems (SRS) 1 — Driver Airbag 2 — Passenger Airbag 3 — Knee Bolster THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 This vehicle has airbags for both the driver and right front passenger as a supplement to the seat belt restraint systems.
Page 53 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If the vehicle is equipped with side airbags, they are located inside the driver and front passenger seats, and their covers are also labeled SRS. Side Airbag Location NOTE: Airbag covers may not be obvious in the interior trim;...
Page 54 The front airbags have a multistage inflator design. This allows the airbag to have different rates of inflation that are based on collision severity. Along with the seat belts, front airbags work with the instrument panel knee bol- sters to provide improved protection for the driver and front passenger.
Page 55 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE seat as far back as possible, and use the proper child restraint. Refer to “Child Restraint” in this section. You should read the instructions provided with your child restraint to make sure that you are using it properly. 2.
Page 56 Airbag System Components The airbag system consists of the following: • Occupant Restraint Control (ORC) Module • Airbag Warning Light • Driver Airbag • Passenger Airbag • Front Seat-Mounted Side Airbags (If Equipped) • Steering Wheel and Column • Instrument Panel •...
Page 57 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Also, the ORC turns on the Airbag Warning Light for six to eight seconds for a self-check when the ignition is first turned on. After the self-check, the Airbag Warning Light will turn off.
Page 58 • The Side Impact (SRS) Seat-Mounted Side Airbags (If Equipped) are designed to activate only in certain side collisions. The ORC determines if a side collision is severe enough to require the side airbags to inflate. The ORC monitors the readiness of the electronic parts of the system whenever the ignition switch is in the START or ON positions.
Page 59 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE passenger as the airbags deploy and unfold. The abrasions are similar to friction rope burns or those you might get sliding along a carpet or gymnasium floor. They are not caused by contact with chemicals. They are not permanent and normally heal quickly.
Page 60 Enhanced Accident Response Feature If the airbags deploy after an impact and the electrical system remains functional, vehicles equipped with power door locks will unlock automatically. The hazard lights will flash and the fuel will be cut off to the engine. In addition, after the vehicle has stopped moving, the interior lights will illuminate to aid visibility and remain lit until the ignition switch is turned off.
Page 61 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Perchlorate Material – special handling may apply, www.dtsc.ca.gov/hazardouswaste/ perchlorate. Airbag Warning Light You will want to have the airbag system ready to inflate for your protection in an impact. The airbag system is designed to be maintenance free.
Page 62 In the event that an investigation is undertaken by DaimlerChrysler Corporation (regardless of initiative), the company, or its designated representative, will first obtain permission of the appropriate custodial entity for the vehicle (usually the vehicle owner or leasee) before accessing the electronic data stored, unless ordered to download data by a court with legal jurisdiction (i.e., pursuant to a warrant).
Page 63: Child Restraint
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Airbag deployment level (if applicable) • Impact acceleration and angle • Seat belt status • Brake status (service and parking brakes) • Accelerator status (including vehicle speed) • Engine control status (including engine speed) •...
Page 64 WARNING! In a collision, an unrestrained child, even a tiny baby, can become a missile inside the vehicle. The force required to hold even an infant on your lap could become so great that you could not hold the child, no matter how strong you are.
Page 65 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Improper installation can lead to failure of an infant or child restraint. It could come loose in a collision. The child could be badly injured or killed. Follow the manufacturer’s directions ex- actly when installing an infant or child restraint.
Page 66 extracted from the retractor. Allow the belt to return to the retractor, pulling on the excess webbing to tighten the lap portion about the child restraint. For additional information, refer to Automatic Locking Mode ear- lier in this section. • In the rear seat, you may have trouble tightening the lap/shoulder belt on the child restraint because the buckle or latch plate is too close to the belt path opening on the restraint.
Page 67 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE vehicle by the lap/shoulder belt or the LATCH child restraint anchorage system (Refer to LATCH — Child Seat Anchorage System in this section). The belt-positioning booster seat is for children weighing more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly.
Page 68 NOTE: To reset this feature you must let all of the belt webbing return into the retractor. You will not be able to pull out more webbing until all of the webbing has been returned back into the retractor. Installing the Child Restraint System We urge you to carefully follow the directions of the manufacturer when installing your child restraint.
Page 69 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LATCH — Child Seat Anchorage System (Lower Anchors and Tether for CHildren) Your vehicle’s rear seat is equipped with the child restraint anchorage system called LATCH. The LATCH system provides for the installation of the child restraint without using the vehicle’s seat belts, instead securing the child restraint using lower anchorages and upper tether straps from the child restraint to the vehicle...
Page 70 The rear seating positions have lower anchorages that are capable of accommodating LATCH-compatible child seats having flexible, webbing-mounted lower attach- ments. Child seats with fixed lower attachments must be installed in the outboard positions only. Regardless of the specific type of lower attachment, NEVER install LATCH-compatible child seats such that two seats share a common lower anchorage.
Page 71 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Latch Anchorages (Two-Door Models) Latch Anchorages (Four-Door Models)
Page 72 In addition, there are tether strap anchorages behind each rear seating position located on the back of the seat. Tether Strap Mounting (Two-Door Models) THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 Tether Strap Mounting (Four-Door Models) Many, but not all restraint systems will be equipped with separate straps on each side, with each having a hook or connector for attachment to the lower anchorage and a means for adjusting the tension of the strap.
Page 73 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE a hook for attachment to the tether strap anchorage, and a means for adjusting the tension of the strap. You will first loosen the adjusters on the lower straps and on the tether strap so that you can more easily attach the hooks or connectors to the vehicle anchorages.
Page 74 If the seat belt has an automatic locking retractor, it will have a distinctive label. Pull the belt from the retractor until there is enough to allow you to pass through the child restraint and slide the latch plate into the buckle. Then, pull the belt until it is fully extended from the retractor.
Page 75 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Tether Strap Mounting (Four-Door Models) Route the tether strap over the seatback and attach the hook to the tether anchor located on the back of the seat. For the outboard seating positions, route the tether under the head rest, and attach the hook to the tether anchor located on the back of the seat.
Page 76: Engine Break-In Recommendations
ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine in your vehicle. Drive moderately during the first 300 mi (500 km). After the initial 60 mi (100 km), speeds up to 50 or 55 mph (80 or 90 km/h) are desirable.
Page 77: Safety Checks You Should Make Inside The Vehicle
76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Do not inhale exhaust gases. They contain carbon monoxide, a colorless and odorless gas which can kill. Never run the engine in a closed area, such as a garage, and never sit in a parked vehicle with the engine running for an extended period.
Page 78: Safety Checks You Should Make Outside The Vehicle
Airbag Warning Light The light should come on and remain on for six to eight seconds as a indicator check when the ignition switch is first turned on. If the indicator is not lit during starting, have it serviced. If the light stays on or comes on while driving, have the system checked by an authorized dealer.
Page 80: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors .......83 Inside Day/Night Mirror ....83 Outside Mirrors .
Page 81 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Raise The Rear Seat ....94 To Open And Close The Hood ....94 Lights .
Page 82 To Accelerate For Passing ....105 Electronic Brake Control System ... . 105 ABS (Anti-Lock Brake System) ... . 105 TCS (Traction Control System) .
Page 83 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Door Frame ......132 Door Frame Removal (Two-Door Models) ..132 Door Frame Installation (Two-Door Models) .
Page 84: Mirrors
MIRRORS Inside Day/Night Mirror The mirror should be adjusted to center on the view through the rear window. A two-point pivot system allows for horizontal and vertical adjustment of the mirror. Adjusting Rearview Mirror UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83 Annoying headlight glare can be reduced by moving the small control under the mirror to the night position (toward rear of vehicle).
Page 85: Outside Mirrors
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Outside Mirrors To receive maximum benefit, adjust the outside mirror(s) to center on the adjacent lane of traffic with a slight overlap of the view obtained on the inside mirror. Outside Rearview Mirror WARNING! •...
Page 86: Hands-Free Communication (Uconnect )
HANDS–FREE COMMUNICATION (UConnect ) This feature is not available on two–door or four–door models. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85 Voice Recognition Button (UConnect Hands-Free Phone) When you press this button, a “Not Equipped with UConnect” message will display on your radio screen. Phone Button (UConnect Hands-Free Phone) When you press this button, a “Not Equipped with UConnect”...
Page 87: Seats
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE SEATS WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust any seat only while the vehicle is parked.
Page 88: Manual Seat Height Adjustment - If Equipped
Manual Seat Height Adjustment — If Equipped The driver’s seat height can be raised or lowered by using the ratcheting handle on the outboard side of the seat. Pull upward on the handle to raise the seat. Push downward on the handle to lower the seat. Seat Height Adjustment UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 Front Seatback Recline...
Page 89: Front Easy Entry Seats (Two-Door Models)
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Easy Entry Seats (Two-Door Models) Push the lever on the seatback rearward (toward the rear of the vehicle) to tilt the entire seat forward. Easy Entry Lever Easy Entry Seat 1. To return the seat to a sitting position, rotate the seatback upright until it locks.
Page 90: Head Restraints
NOTE: The front seats have a full recliner memory, which will allow the seatback to be returned to its original position. NOTE: The front seats have a track memory, which returns the seat to just past the halfway point of the track regardless of its original position.
Page 91 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Also, be sure that the front seats are fully upright and positioned forward. This will allow the rear seat to fold down easily. 1. Lift the seatback release lever and fold seatback for- ward.
Page 92: Removing The Rear Seat (Two-Door Models)
Removing the Rear Seat (Two-Door Models) WARNING! • It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision people riding in these areas are more likely to be seri- ously injured or killed. •...
Page 93: Replacing The Rear Seat (Two-Door Models)
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Press down on the release bar on each side, and pull the seat out and away from lower bracket. 5. Remove the seat from the vehicle. Release Bar Location Replacing the Rear Seat (Two-Door Models) Reverse steps for removing the seat.
Page 94 NOTE: Prior to folding the rear seat, it may be necessary to reposition the front seat to its mid-track position. Also, be sure that the front seats are fully upright and positioned forward. This will allow the rear seat to fold down easily.
Page 95: To Raise The Rear Seat
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Raise the Rear Seat 1. Raise the seatback and lock it into place. If interference from the cargo area prevents the seatback from fully locking, you will have difficulty returning the seat to its proper position.
Page 96: Lights
Next, locate handle in middle of the front end of the hood. Insert hand into gap between hood and top of grille, and push handle to the side to raise hood. You may have to push down slightly on the hood before pushing the handle.
Page 97 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Also, the rear cargo lamp may be turned on by pressing the lens. Press the lens again to turn it off. Cargo Lamp When a door is open and the interior lights are on, rotating the dimmer control all the way down to the OFF detent will cause all the interior lights to turn off.
Page 98: Multifunction Control Lever
Daytime Brightness Feature Certain instrument panel components (odometer, radio display) can be illuminated at full brightness during the daytime. This can be helpful when driving with your headlights on during the daytime, such as in a parade or a funeral procession. To activate this feature, rotate the left stalk one detent lower than the dome light.
Page 99: Lights-On Reminder
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Lens fogging can occur under certain atmo- spheric conditions. This will usually clear as atmospheric conditions change to allow the condensation to change back into a vapor. Turning the lamps on will usually accelerate the clearing process.
Page 100: Passing Light
Passing Light You can signal another vehicle with your headlights by lightly pulling the multifunction control lever toward the steering wheel. This will cause the headlights to turn on at high beam and remain on until the lever is released. Front Fog Lights —...
Page 101: Windshield Wipers And Washers
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS CAUTION! In cold weather, always turn off the wiper switch and allow the wipers to return to the park position before turning off the engine. If the wiper switch is left on and the wipers freeze to the windshield, damage to the wiper motor may occur when the vehicle is restarted.
Page 102: Windshield Washers
Windshield Washers To use the washer, pull the lever toward you and hold while spray is desired. If the lever is pulled while in the delay range, the wiper will operate for two wipe cycles after the lever is released, and then resume the intermit- tent interval previously selected.
Page 103: Electronic Speed Control - If Equipped
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Tilting the steering column while the vehicle is moving is dangerous. Without a stable steering col- umn, you could lose control of the vehicle and have an accident. Adjust the column only while the ve- hicle is stopped.
Page 104: To Set At A Desired Speed
WARNING! Leaving the Electronic Speed Control System on when not in use is dangerous. You could accidentally set the system or cause it to go faster than you want. You could lose control and have an accident. Always leave the system OFF when you are not using it. To Set At A Desired Speed When the vehicle has reached the desired speed, press down on the lever and release.
Page 105: Manual Transmission
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Tapping RESUME ACCEL once will result in a 1 mph (1.6 km/h) speed increase. Each time the lever is tapped, speed increases so that tapping the lever three times will increase speed by 3 mph (4.8 km/h), etc. To decrease speed while speed control is ON, push down and hold SET DECEL.
Page 106: To Accelerate For Passing
To Accelerate For Passing Depress the accelerator as you would normally. When the pedal is released, the vehicle will return to the set speed. Using Speed Control On Hills NOTE: The speed control system maintains speed up and down hills. A slight speed change on moderate hills is normal.
Page 107: Tcs (Traction Control System)
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! ABS (Anti-Lock Brake System) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions. ABS cannot prevent accidents, in- cluding those resulting from excessive speed in turns, driving on very slippery surfaces, or hydro- planing.
Page 108: Bas (Brake Assist System)
BAS (Brake Assist System) The BAS is designed to optimize the vehicle’s braking capability during emergency braking maneuvers. The system detects an emergency braking situation by sens- ing the rate and amount of brake application and then applies optimum pressure to the brakes. This can help reduce braking distances.
Page 109: Erm (Electronic Roll Mitigation)
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ERM (Electronic Roll Mitigation) This system anticipates the potential for wheel lift by monitoring the driver’s steering wheel input and the speed of the vehicle. When ERM determines that the rate of change of the steering wheel angle and vehicles speed are sufficient to potentially cause wheel lift, it applies the appropriate brake and may reduce engine power to lessen the chance that wheel lift will occur.
Page 110: Esp (Electronic Stability Program)
ESP (Electronic Stability Program) This system enhances directional control and stability of the vehicle under various driving conditions. ESP cor- rects for over/under steering of the vehicle by applying the brake of the appropriate wheel to assist in counter- acting the over/under steer condition. Engine power may also be reduced to help the vehicle maintain the desired path.
Page 111 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! ESP (Electronic Stability Program) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions. ESP cannot prevent accidents, in- cluding those resulting from excessive speed in turns, driving on very slippery surfaces, or hydro- planing.
Page 112 required to gain traction. To turn ESP on again, momen- tarily depress the ESP OFF switch. This will restore the normal “ESP On” mode of operation. ESP OFF Switch NOTE: To improve the vehicle’s traction when driving with snow chains, or starting off in deep snow, sand, or gravel, it may be desirable to switch to the “Partial Off”...
Page 113 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE again, momentarily depress the ESP OFF switch. This will restore the normal “ESP On” mode of operation. NOTE: The ESP system will change to “Partial Off” mode if the vehicle speed exceeds 40 mph (64 km/h). After the vehicle speed is reduced below 35 mph (56 km/h), the ESP system will return to “Full Off”...
Page 114 40 mph (48 km/h), the normal ESP stability function returns but TCS remains off. When the vehicle speed drops below 35 mph (40 km/h), the ESP system shuts off. ESP is off at low vehicle speeds in 4L range so that it will not interfere with off-road driving, but the ESP function returns to provide the stability feature at speeds above 40 mph (48 km/h).
Page 115 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE maneuver must be performed to permanently disable ESP and defeat the functionality of the ESP switch. Repeating the procedure will return the system to normal ESP operation and restore ESP switch functionality al- lowing ESP “Partial”...
Page 116: Esp/Bas Warning Light
9. Turn the steering wheel back to center. 10. Press and hold the ESP OFF button for seven seconds. 11. Cycle the ignition key to OFF. After performing the ESP disable procedure correctly, “ESP OFF” will be displayed in the odometer for approxi- mately 12 seconds each time the ignition is moved to ON.
Page 117: Electrical Power Outlet
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ELECTRICAL POWER OUTLET This vehicle has two auxiliary power outlets that can provide up to 20 Amps of current for accessories de- signed for use with the standard power outlet adapters. The outlet located in the lower portion of the instrument panel has a snap-on plastic cap so that it can be covered when not in use.
Page 118: Electrical Outlet Use With Engine Off
Electrical Outlet Use With Engine Off WARNING! • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e., cellular phones, etc.). Eventually, if plugged in long enough, the vehicle’s battery will discharge suffi- ciently to degrade battery life and/or prevent engine starting.
Page 119: Rear Cupholders
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Cupholders The rear cupholders are located on the back of the center console. Rear Cupholders STORAGE Console Storage Compartment To lock or unlock, insert ignition key and turn. To open, press the latch and lift cover. Center Console...
Page 120: Rear Storage Compartment
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 Rear Storage Compartment The rear storage compartment cover is held by a spring- loaded latch. In order to remove the rear storage com- partment cover, use the following procedure: NOTE: The rear storage compartment latch should not be used as cargo tie-down.
Page 121: Dual Top - If Equipped
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE DUAL TOP — IF EQUIPPED If your vehicle is equipped with a Dual Top, you must remove one of the tops from the vehicle. If the soft top is removed, the pivot brackets must also be removed from the sport bar.
Page 122 3. Remove the soft top bow assembly pivot bracket screws (two per side) using a #T30 Torx head driver. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 4. Using a rubber mallet, carefully tap the knuckles from the left and right metal pivot brackets. Remove the soft top from the vehicle and store in a clean, dry location.
Page 123: Installing The Soft Top
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 5. Unzip the zipper on the sport bar cover to expose the pivot brackets. Remove the brackets using a #T30 Torx head driver. Recover and re-zip the sports bar cover. Store pivot brackets and screws in a safe place. 6.
Page 124 3. Install the door frames. Refer to “Door Frame” in this section. 4. If the soft top has been removed, follow these steps to reinstall the soft top. If the soft top is on the vehicle, proceed to step #5. a.
Page 125 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE c. Tap the knuckles on the side with a rubber mallet to reattach them to the metal pivot brackets. d. Screw the pivot screws back into place using a #T30 Torx head driver. Secure them until they are snug being careful not to cross-thread the screws or over- tighten.
Page 126: Freedom Top Three-Piece Modular Hard Top
5. Unsnap and remove the black boot cover. This cover should be discarded. It was intended as a protective cover for shipping only. NOTE: A visual instruction sheet is enclosed in the dual top wrap. 6. Remove the swing gate bar (black metal bar for bottom of rear window) and set aside.
Page 127: Front Panel(S) Removal
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Panel(s) Removal NOTE: Left panel must be removed before removing right panel. 1. Fold down the sun visor, and move to the side. 2. Turn center L-shaped locks (2) from center of roof panel.
Page 128 4. Turn rear fasteners (knobs) (located on overhead speaker bar assembly) counterclockwise until they can be removed. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 5. Unlatch the header panel latch located at the top of the windshield. 6. Remove panel. To remove right panel, follow steps above except for step...
Page 129: Front Panel(S) Installation
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Panel(s) Installation NOTE: The front panel(s) must be positioned properly to ensure sealing. Set the panels on the windshield frame so that there is no overhang. Also, make sure that the panels are sitting flush with the body. 1.
Page 130: Rear Hard Top Removal
3. Reinstall panel(s) using the same steps for removal in reverse order. Rear Hard Top Removal 1. Remove both front panels. Refer to “Front Panel(s) Removal” in this section. 2. Open both doors. 3. Remove the two Torx head screws that secure the hard top at the B-pillar (near top of door) using a #40 Torx head driver (4–Door Only).
Page 131 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 6. Locate the wiring harness on the left rear inside corner of the vehicle. 7. Disconnect the rear window washer hose and install the tethered cap. CAUTION! Make sure storage cap is installed to prevent foreign materials from entering washer tube and clogging system, and also to prevent fluid from being sprayed into the rear of the vehicle.
Page 132: Rear Hard Top Installation
9. Close the swing gate. 10. Remove the hard top from the vehicle. Place on a soft surface to prevent damage. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 Rear Hard Top Installation NOTE: If the door frames are installed from soft top usage, they must be removed prior to installation of the hard top.
Page 133: Door Frame
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE DOOR FRAME WARNING! Do not drive your vehicle on pavement with the door frame(s) removed as you will lose the protection that they can provide. This procedure is furnished for use during off-road operation only. Door Frame Removal (Two-Door Models) 1.
Page 134 2. Place one hand on the upper rear and one hand on the front of the door frame. 3. Pull the frame towards you with your rearward hand to remove the frame from the vehicle. 4. Screw the knobs back into the door frame and fold for storage.
Page 135: Door Frame Installation (Two-Door Models)
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Door Frame Installation (Two-Door Models) 1. Unfold door frame and unscrew thumbscrews. 2. Set the door frame pin into the hole on top of the body side, behind the door opening. 3. After the door frame pin has been set into the body side hole, carefully set the front of the door frame into the rubber seal at the top of the windshield.
Page 136: Door Frame Removal (Four-Door Models)
5. Starting with the front knob, screw in and tighten both knobs. Repeat on the other side. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 Door Frame Removal (Four-Door Models) 1. Unscrew and remove the two forward most door frame attachment knobs.
Page 137 136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Use both hands to remove the door frames. The door frames will fold and could cause injury if both hands are not used. 2. Place one hand on the upper rear and one hand on the upper front of the front door frame.
Page 138 4. Unscrew and remove the remaining door frame at- tachment knob on the rear door frame. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 5. Place one hand on the upper rear and one hand on the upper front of the rear door frame. Pull the frame towards you with your rear hand to remove the frame from the vehicle.
Page 139: Door Frame Installation (Four-Door Models)
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 6. Screw the knob back into the door frame and fold for storage. Store in a secure location. WARNING! • Never store the door frames in your vehicle. In an event of an accident, a loose door frame many cause personal injury.
Page 140 3. Position the top of the door frame against the metal sport bar and press onto the side bar making sure not to pinch the material of the sports bar covers and to ensure it is properly positioned on the seal above the front of the rear door.
Page 141 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 5. Carefully set the front of the front door frame in the rubber seal at the top of the windshield. Then, clip the front of the door rail over the side bar making sure that the material for the side bar cover is not pinched by the door frame.
Page 142: Soft Top (Two-Door Models)
SOFT TOP (TWO-DOOR MODELS) CAUTION! • The soft top is not designed to carry any additional loads such as roof racks, spare tires, building, hunting, or camping supplies, and/or luggage, etc. Also, it was not designed as a structural member of the vehicle, and thus cannot properly carry any additional loads other than environmental (rain, snow, etc.).
Page 143 142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! • Do not run a fabric top through an automatic car wash. Window scratches and wax build up may result. • Do not lower the top when the temperature is below 41°F (5°C). Damage to the top may result. •...
Page 144: Folding Down The Soft Top
Folding Down The Soft Top 1 — Header Bow 2 — 2–Bow 3 — 3–Bow 4 — Sail Panel 5 — Plastic Retainer UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 6 — Body Side Retainer 7 — Quarter Window 8 — Check Strap 9 —...
Page 145 144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 1 — Zipper Start 2 — Zipper Finish 3 — Swing Gate Bar 4 — Swing Gate Brackets 5 — Sail Panels...
Page 146 NOTE: Clean side and rear windows before removal to assist in preventing scratching during removal of the soft top. If zippers are difficult to operate due to road dust, etc., clean them with a mild soap solution and a small brush.
Page 147 146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Unclip and move the sun visors to the side. 4. Release the header latches and leave the hooks in the loops on the windshield. 5. Open the swing gate. 6. Before unzipping the rear window, release the first 3 in (7.6 cm) of both sail panels from the channel.
Page 148 • Unzip the rear window starting at the right lower corner of the window. Pull the zipper up, across the top and down to the left lower corner. Zipper pulls will stay on the rear window. Pull down on the rear window to disengage from the zipper on the top cover.
Page 149 148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 10. Finish releasing the sail panel retainers from the body side channel at the rear corners of the vehicle. NOTE: When releasing the sail panel retainers, it is helpful to pull down on the rear roof bow. 11.
Page 150 12. The swing gate brackets do not need to be removed unless the hard top is being installed. To remove the swing gate brackets, pull the front of the bracket forward while rolling the entire bracket back in towards the vehicle to disengage.
Page 151 150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 14. Make sure the plastic sleeves are slid forward over the Sunrider link (Sunrider Models Only). 15. Unlatch the side bows from both door rails (Sunrider Models Only).
Page 152 16. Before lowering the top, open the swing gate to prevent possible damage to the rear center high-mounted brake lamp. Move to the front of the vehicle. Grasp the side bow behind the header and lift the top, folding it toward the rear of the vehicle.
Page 153: Putting Up The Soft Top
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Putting Up The Soft Top 1 — Header Bow 2 — 2– Bow 3 — 3–Bow 4 — Sail Panel 5 — Plastic Retainer 6 — Body Side Retainer 7 — Quarter Window 8 —...
Page 154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 1 — Zipper Start 2 — Zipper Finish 3 — Swing Gate Bar 4 — Swing Gate Brackets 5 — Sail Panels...
Page 155 154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 1. Unclip and move the sun visors to the side. 2. Install door frames, if removed. Refer to “Door Frame” in this section. 3. Make sure the plastic sleeve is slid rearward over Sunrider link (Sunrider Models Only).
Page 156 6. Make sure the Sunrider bracket on the side bows latches to the door rails (Sunrider Models Only). 7. Open the header latches and engage the hook on each side onto the windshield loops (do not close the latches). UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 8.
Page 157 156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 9. Move to the rear of the vehicle and gently pull the sail panels over the rear roof bow. 10. Partially install the sail panel retainers into the body side channel, leaving the last 3 in (7.6 cm) towards the rear window loose (on both sides).
Page 158 11. To install the side windows, affix the window tem- porarily by attaching to the Velcro in the rear corner. Start the zipper but close only about 1 in (2.5 cm). UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 12. Insert the front retainer of the window into the door channel, making sure the retainer is fully seated and properly positioned on the door frame.
Page 159 158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 13. Continue closing the zipper only along the top edge of the window. 14. Insert the retainer along the bottom edge of the window into the bottom side channel, beginning at the front and working to the rear of the vehicle. Finish by closing the zipper completely and attaching the Velcro along the top and rear of the window.
Page 160 15. Locate the black swing gate bar. Slide the swing gate bar over the receiver at the bottom inside of the rear window. The spongy part of the seal should be down and pointed outward to seal with the swing gate when closed. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 16.
Page 161 160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 18. Grasp the swing gate bar and position it into the swing gate brackets. 19. Apply downward pressure on the top corner of the rear soft top bow (3–bow), then complete attaching the sail panel retainers into the body side channel.
Page 162: Sunrider (Two-Door Models) - If Equipped
SUNRIDER (TWO-DOOR MODELS) — IF EQUIPPED NOTE: If you are going to be driving faster than 40 mph (64 km/h) with the Sunrider feature open, it is recom- mended that you remove the rear window of the vehicle. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 To Open 1.
Page 163 162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Unclip and move the sun visors to the side. 4. Slide the plastic sleeve forward. 3. Release the header latches from the loops on the windshield frame.
Page 164 5. Grasp the header and lift the top back. Make sure the material is folded back as shown. NOTE: The Sunrider latch on the door rail should not be activated for Sunrider use. If activated, the soft top must be reinstalled starting from the sail panels. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 6.
Page 165: Sunrider (Four-Door Models) - If Equipped
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Close 1. Remove straps from side bows. 2. Unclip and move sun visors to the side. 3. Grasp the front header and pull to the front of the vehicle. 4. Hook header latches to the loops on the windshield frame, close latches, and return sun visor’s to their original position.
Page 166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 3. Release the header latches from the loops on the windshield frame. 2. Unclip and move the sun visors to the side.
Page 167 166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Grasp the front side bow behind the header, and lift the top. 5. Fold back the front section of the top, and gently rest the header on top of the rear portion of the deck.
Page 168 6. Fold the top material so that the plastic retainers form a “W” as shown. Enter the vehicle, and move the material into two folds. Ensure that the straps are securely stowed. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 7. Close the front header latches. 8.
Page 169: Soft Top (Four-Door Models)
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE SOFT TOP (FOUR-DOOR MODELS) CAUTION! • The soft top is not designed to carry any additional loads such as roof racks, spare tires, building, hunting, or camping supplies, and/or luggage, etc. Also, it was not designed as a structural member of the vehicle, and thus cannot properly carry any additional loads other than environmental (rain, snow, etc.).
Page 170 CAUTION! • Do not run a fabric top through an automatic car wash. Window scratches and wax build-up may result. • Do not lower the top when the temperature is below 41°F (5°C). Damage to the top may result. • Do not lower the top when the windows are dirty. Grit may scratch the window.
Page 171: Folding Down The Soft Top
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Folding Down The Soft Top 1 — Header Bow 2 — 2–Bow 3 — 3–Bow 4 — 4–Bow 5 — Sail Panel 6 — Body Side Retainer 7 — Quarter Window 8 — Check Strap 9 —...
Page 172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 1 — Zipper Start 2 — Zipper Finish 3 — Swing Gate Bar 4 — Swing Gate Brackets 5 — Sail Panels...
Page 173 172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Clean side and rear windows before removal to assist in preventing scratching during removal of the soft top. If zippers are difficult to operate due to road dust, etc., clean them with a mild soap solution and a small brush.
Page 174 4. Release the header latches and hooks from the loops on the windshield frame. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 5. Open the swing gate. 6. Before unzipping the rear window, release the first 3 in (7.6 cm) of both sail panels from the channel. Remove the swing gate bar by pulling it straight rearward out of the swing gate brackets.
Page 175 174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Unzip the rear window starting at the right lower corner of the window. Pull the zipper up, across the top and down to the left lower corner. Zipper pulls will stay on the rear window. Pull down on the rear window to disengage from the zipper on the top cover.
Page 176 10. Finish releasing the sail panel retainers from the body side channel at the rear corners of the vehicle. NOTE: When releasing the sail panel retainers, it is helpful to pull down on the rear roof bow. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 11.
Page 177 176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 12. The swing gate brackets do not need to be removed unless the hard top is being installed. To remove the swing gate brackets, pull the front of the bracket forward while rolling the entire bracket back in towards the vehicle to disengage.
Page 178 14. Fold back the front section of the top, and gently rest the header on top of the rear portion of the deck. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177 15. Fold the top material so that the plastic retainers form a “W”...
Page 179 178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 16. Release the side bows by pressing down on the latch above the front of the rear door. Push the top rearward to disengage. Repeat this step on the other side. 17. Grasp the folded side bows and slide the top along the door frame track to the rear door frame.
Page 180 18. Before lowering the top, open the swing gate to prevent possible damage to the rear center high-mounted brake lamp. Gently slide the side bows off the door frame track and lower the top down into the vehicle. 19. Tuck the fabric and the check straps between the bows as far inside as possible.
Page 181: Putting Up The Soft Top
180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Putting Up The Soft Top 1 — Header Bow 2 — 2–Bow 3 — 3–Bow 4 — 4–Bow 5 — Sail Panel 6 — Body Side Retainer 7 — Quarter Window 8 — Check Strap 9 —...
Page 182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181 1 — Zipper Start 2 — Zipper Finish 3 — Swing Gate Bar 4 — Swing Gate Brackets 5 — Sail Panels...
Page 183 182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Be extremely careful when putting up the soft top to prevent the doors from getting scratched. It may be helpful to open the rear doors. 1. Install the door frames, if removed. Refer to “Door Frame”...
Page 184 5. Insert the slider feature of the knuckles into the door frame tracks and slide the top forward. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183 6. Ensure that the top locks into Sunrider locking mecha- nisms that are located above the front of the rear doors.
Page 185 184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 7. Unclip and move the sun visors to the side. 8. Standing on the side of the vehicle, lift the top by the side bow until it rests on the windshield frame. 9. Before attaching the header latches, be sure the top retainers above the doors do not get trapped between the top and the door frame.
Page 186 10. Open the header latches and engage the hook on each side onto the windshield loops (do not close the latches). 11. If the swing gate brackets were removed, install them by hooking the rear edge of the bracket on the interior side of the body channel.
Page 187 186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 13. Partially install the sail panel retainers into the body side channel, leaving the last 3 in (7.6 cm) towards the rear window loose (on both sides). Pulling down on the rear roof bow (4–bow) will aid to reach the channel with the retainers.
Page 188 15. Insert the front retainer of the window into the door channel, making sure the retainer is fully seated and properly positioned on the door frame. Failure to do so can result in wind and water leaks or damage to the window.
Page 189 188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 17. Insert the retainer along the bottom edge of the window into the bottom side channel, beginning at the front and working to the rear of the vehicle. Finish by closing the zipper completely and attaching the Velcro along the top and rear of the window.
Page 190 19. Install the rear window by starting both zipper ends at the lower left corner of the rear window opening. Ensure that the zippers are properly started and aligned before zipping to prevent damage. 20. Run the first zipper fully around to the right side of the window.
Page 191 190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 23. Open the doors and insert the top retainers into the channels in the door frame above the doors, starting at the front and working toward the rear of the vehicle. 24. Ensure plastic retainer is tucked in properly at B-pillar, not pinching the seal.
Page 192: Folding Windshield
25. Close the header latches and return the sun visors to their secured position. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 191 FOLDING WINDSHIELD The fold-down windshield and removable side bars on your vehicle are structural elements that can provide some protection in some accidents. The windshield also provides some protection against weather, road debris and intrusion of small branches and other objects.
Page 193 192 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Raise the windshield and reinstall the side bars as soon as the task that required their removal is completed and before you return to on-road driving. Both you and your passenger should wear seat belts at all times, on-road and off-road, regardless of whether the windshield is raised or folded down.
Page 194: Lowering The Windshield And Removing Side Bars
Lowering The Windshield And Removing Side Bars 1. Lower the fabric top or remove the hard top following the instructions in this manual. NOTE: To assist in properly reinstalling side bars, mark the original locations prior to removing. 2. Remove the two top hex bolts (13 mm), and the one side hex bolt (13 mm) visible through the trim (Do not remove plastic corner trim, sun visor bolts, or sport bar covering).
Page 195 194 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Pull side bar out horizontally when removing. CAUTION! Do not remove the head impact foam from the side bars, as damage to the foam may result. NOTE: Store all of the mounting bolts in their original threaded holes and tighten for safekeeping.
Page 196 7. Remove the windshield wiper arms by first pulling the wiper away from the windshield and out to the “lock” position. Unsnap the wiper arm nut caps, and remove retaining nuts. Lift the wiper arms off and store in center console or securely behind the rear seat. 8.
Page 197: Bars
196 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Raising The Windshield And Replacing Side Bars 1. Raise the windshield. 2. Loosely attach rear of side bar to sport bar. Refer to Step 4 of “Lowering Windshield And Removing Side Bars” earlier in this section. •...
Page 198: Rear Window Features - Hard Top Only
5. Install the lower windshield plates with the six black round-headed Torx head screws (using a #40 Torx head driver) on each side of the base of the windshield. 6. Reinstall wiper arms. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 197 REAR WINDOW FEATURES —...
Page 199: Rear Window Defroster - If Equipped
198 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Windshield Wiper/Washer Switch If the rear wiper is operating when the ignition is turned OFF, the wiper will automatically return to the “Park” position. When the vehicle is restarted, the wiper will resume function at whichever position the switch is set Adding Washer Fluid The fluid reservoir for the windshield washers and the rear window washer is shared.
Page 200 The defroster will automatically turn off after about ten minutes. For five more minutes of operation, press the switch again. To prevent excessive battery drain, use the defroster only when the engine is operating. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 199 CAUTION! Use care when washing the inside of the rear window to prevent damage to heating elements.
Page 202: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel And Controls ... . . 204 Instrument Cluster ..... . 205 Instrument Cluster Description .
Page 203 202 UNDERSTANDING YOUR INSTRUMENT PANEL List Button (CD Mode For MP3 Play) ..233 Info Button (CD Mode For MP3 Play) ..233 Sales Code REQ — AM/FM Stereo Radio And 6–Disc CD/DVD Changer (MP3/WMA AUX Jack) .
Page 204 Operating Instructions - Hands-Free Phone (If Equipped) ......257 Operating Instructions - Video Entertainment System (VES ) (If Equipped) ... . . 258 CD/DVD Disc Maintenance .
Page 205: Instrument Panel And Controls
204 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL AND CONTROLS 1 — Air Outlet 2 — Instrument Cluster 3 — Horn 4 — Radio 5 — Glove Box 6 — Climate Controls 7 — Power Outlet 8 — Lower Switch Bank 9 —...
Page 206: Instrument Cluster
UNDERSTANDING YOUR INSTRUMENT PANEL 205 INSTRUMENT CLUSTER...
Page 207: Instrument Cluster Description
206 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTION Your vehicle is equipped with the instrument cluster described on the following pages. 1. Fuel Gauge The pointer shows the level of fuel in the fuel tank. NOTE: When the ignition switch is turned to OFF, the fuel gauge, voltmeter, oil pressure and temperature gauges may not show accurate readings.
Page 208 7. Seat Belt Indicator Light A warning chime and an indicator light will alert you to buckle the seat belts. When the belt is buckled, the chime will stop, but the light will stay on until it times out (about six seconds). 8.
Page 209 208 UNDERSTANDING YOUR INSTRUMENT PANEL off, it indicates a possible brake system fluid leak or low pressure level, see your authorized dealer immediately. If the parking brake is applied and the vehicle is in motion, the Brake Warning Light will “flash” and a chime will sound.
Page 210 15. Tachometer This light indicates the engine speed in revolutions per minute (RPM). CAUTION! Do not operate the engine with the tachometer pointer in the red area. Engine damage will occur. 16. Engine Coolant Temperature Warning Light This light warns of an overheated engine condi- tion.
Page 211 210 UNDERSTANDING YOUR INSTRUMENT PANEL 21. Odometer/Trip Odometer Reset Button Press this button to change the display from odometer to either of two trip odometer settings. Trip A or Trip B will appear when in the trip odometer mode. Press and hold the button for two seconds to reset the trip odometer to 0 miles or kilometers.
Page 212 Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly. The TPMS malfunction indicator is combined with the low tire pressure telltale. When the system detects a malfunction, the telltale will flash for approximately one minute and then remain continuously illuminated.
Page 213 212 UNDERSTANDING YOUR INSTRUMENT PANEL U.S. federal regulations require that upon transfer of vehicle ownership, the seller certify to the purchaser the correct mileage that the vehicle has been driven. There- fore, if the odometer reading is changed during repair or replacement, be sure to keep a record of the reading before and after the service so the correct mileage can be determined.
Page 214 2. Fully depress the accelerator pedal slowly three times within 10 seconds. 3. Turn the ignition switch to the OFF/LOCK position. NOTE: If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset. If necessary repeat this procedure. 25.
Page 215 214 UNDERSTANDING YOUR INSTRUMENT PANEL will flash anytime the ESP or TCS is active and helping to improve vehicle stability. If the ESP/TCS Indicator Light is on solid, the ESP system has been turned off by the driver or a temporary condition exists that will not allow full ESP function.
Page 216: Compass And Trip Computer - If Equipped
If the light continues to flash when the engine is running, immediate service is required and you may experience reduced performance, an elevated/rough idle, or engine stall and your vehicle may require towing. The light will come on when the ignition is first turned on and remain on briefly as a bulb check.
Page 217: Control Buttons
216 UNDERSTANDING YOUR INSTRUMENT PANEL Control Buttons Press and release the left button (on the instrument cluster) to access the computer displays. Press and hold the left button (on the instrument cluster) for two to three seconds to switch from English to Metric displays.
Page 218: Compass Temperature Display
Trip Odometer (ODO) This display shows the distance traveled since the last reset. Press and release the right button (on the instru- ment cluster) to switch from odometer, to Trip A or Trip B. Press and hold the right button while the odometer/ trip odometer is displayed to reset.
Page 219 218 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Magnetic materials should be kept away from the top of the instrument panel above the radio. This is where the compass sensor is located. Automatic Compass Calibration The self-calibrating feature of the compass eliminates the need to calibrate the compass for normal conditions.
Page 220 When the CAL symbol is no longer displayed, the compass is calibrated and should display correct head- ings. Verify proper calibration by checking North (N), South (S), East (E), and West (W). If the compass does not appear accurate, repeat the calibration procedure in an- other area.
Page 221: Radio General Information
220 UNDERSTANDING YOUR INSTRUMENT PANEL Outside Temperature If the outside temperature is more than 131°F (55°C), the display will show 131°F (55°C). When the outside tem- perature is less than 40°F ( 40°C), the display will show 40°F ( 40°C). RADIO GENERAL INFORMATION Radio Broadcast Signals The radio will provide excellent reception under most...
Page 222: Two Types Of Signals
Two Types of Signals There are two basic types of radio signals: AM or Amplitude Modulation, in which the transmitted sound causes the amplitude, or height, of the radio waves to vary; and FM or Frequency Modulation, in which the frequency of the wave is varied to carry the sound.
Page 223: Sales Code Res - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)
222 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE RES — AM/FM STEREO RADIO WITH CD PLAYER (MP3 AUX JACK) NOTE: The radio sales code is located on the lower right side of your radio faceplate. RES Radio (Non-Satellite Model Shown - With Satellite Similar) Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC...
Page 224 to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection. Holding either button will bypass stations without stopping until you release it. SCAN Button Pressing the SCAN button causes the tuner to search for the next listenable station in AM or FM frequencies, pausing for five seconds at each listenable station before continuing to the next.
Page 225 224 UNDERSTANDING YOUR INSTRUMENT PANEL Clock Setting Procedure 1. Press and hold the TIME button, until the hours blink. 2. Adjust the hours by turning the right side TUNE/ SCROLL control knob. 3. After adjusting the hours, press the right side TUNE/ SCROLL control knob to set the minutes.
Page 226 Setting the Tone, Balance, and Fade Push the rotary TUNE/SCROLL control knob and BASS will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the bass tones. Push the rotary TUNE/SCROLL control knob a second time and MID will display.
Page 227 226 UNDERSTANDING YOUR INSTRUMENT PANEL Toggle the MUSIC TYPE button to select the following format types: 16-Digit Character Program Type No program type or undefined Adult Hits Classical Classic Rock College Country Foreign Language Information Jazz News Nostalgia Oldies Program Type Personality Display Rhythm and Blues...
Page 228 station with the same selected Music Type name. The Music Type function only operates when in the FM mode. If a preset button is activated while in the Music Type (Program Type) mode, the Music Type mode will be exited and the radio will tune to the preset station. SETUP Button Pressing the SETUP button allows you to select between the following items:...
Page 229: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
228 UNDERSTANDING YOUR INSTRUMENT PANEL Every time a preset button is used, a corresponding button number will display. Buttons 1 - 6 These buttons tune the radio to the stations that you commit to pushbutton memory (12 AM and 12 FM stations).
Page 230 CAUTION! • This CD player will accept 4–3/4 in (12 cm) discs only. The use of other sized discs may damage the CD player mechanism. • Do not use adhesive labels. These labels can peel away and jam the player mechanism. •...
Page 231: Notes On Playing Mp3 Files
230 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button Press this button to change the display from a large CD playing time display to a small CD playing time display. RW/FF Press the RW button to stop the CD at the beginning of the current CD track/title.
Page 232 files properly and may be unable to play the file nor- mally. UDF and Apple HFS formats are not supported. The radio uses the following limits for file systems: • Maximum number of folder levels: 8 • Maximum number of files: 255 •...
Page 233 232 UNDERSTANDING YOUR INSTRUMENT PANEL rates (VBR) are also supported. The majority of MP3 files use a 44.1 kHz sampling rate and a 192, 160, 128, 96 or VBR bit rates. MPEG Specifi- Sampling Fre- cation quency (kHz) MPEG-1 Audio 48, 44.1, 32 Layer 3 MPEG-2 Audio...
Page 234: List Button (Cd Mode For Mp3 Play)
LIST Button (CD Mode for MP3 Play) Pressing the LIST button will bring up a list of all folders on the disc. Scrolling up or down the list is done by turning the TUNE/SCROLL control knob. Selecting a folder by pressing the TUNE/SCROLL control knob will begin playing the files contained in that folder (or the next folder in sequence if the selection does not contain playable files).
Page 235: Sales Code Req - Am/Fm Stereo Radio And 6-Disc Cd/Dvd Changer (Mp3/Wma Aux Jack)
234 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button (Auxiliary Mode) Press this button to change the display to time of day. The time of day will display for five seconds (when ignition is OFF). Operating Instructions - Hands-Free Phone (UConnect ) (If Equipped) Refer to “Hands-Free Communication (UConnect )”...
Page 236: Operating Instructions - Radio Mode
Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Press the ON/VOLUME control knob a second time to turn off the radio.
Page 237 236 UNDERSTANDING YOUR INSTRUMENT PANEL Phone Button (UConnect Hands-Free Phone) — If Equipped Press this button to operate the Hands-Free Phone (UConnect ) feature (if equipped). Refer to “Hands-Free Communication (UConnect )” in Section 3. If your vehicle is not equipped with or this feature is not available on your vehicle, a “Not Equipped With UConnect”...
Page 238 RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows. This feature operates in AM, FM or Satellite (if equipped) frequencies. TUNE Control Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the frequency.
Page 239 238 UNDERSTANDING YOUR INSTRUMENT PANEL MUSIC TYPE Button Pressing this button once will turn on the Music Type mode for five seconds. Pressing the MUSIC TYPE button or turning the TUNE/SCROLL control knob within five seconds will allow the program format type to be se- lected.
Page 240 16-Digit Character Dis- Program Type Sports Talk Top 40 Weather By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency station with the same selected Music Type name. The Music Type function only operates when in the FM mode.
Page 241 240 UNDERSTANDING YOUR INSTRUMENT PANEL • Audio Stream – Repeatedly pressing SELECT will switch to different audio languages (if supported on the disc) (if equipped). • Angle – Repeatedly pressing SELECT will change the viewing angle if supported by the DVD disc (if equipped).
Page 242 Enter the four-digit country code using the TUNE/ SCROLL control knob to scroll up and down to select the number and then push to select. Audio Language — If Equipped Selecting this item allows you to choose a default audio language (effective only if the language is supported by the disc).
Page 243 242 UNDERSTANDING YOUR INSTRUMENT PANEL auto-play the main title. In such cases, use the MENU button on the remote control to select desired title to play. NOTE: The user will have to set these defaults before loading a disc. If changes are made to these settings after a disc is loaded, changes will not be effective.
Page 244: Operation Instructions - (Disc Mode For Cd And Mp3/Wma Audio Play, Dvd-Video)
Operation Instructions - (DISC MODE for CD and MP3/WMA Audio Play, DVD-VIDEO) The radio DVD player and many DVD discs are coded by geographic region. These region codes must match in order for the disc to play. If the region code for the DVD disc does not match the region code for the radio DVD player, it will not play the disc.
Page 245 244 UNDERSTANDING YOUR INSTRUMENT PANEL Eject Button — Ejecting Compact Disc(s) Press the EJECT button and the pushbutton with the corresponding number (1-6) where the CD was loaded and the disc will unload and move to the entrance for easy removal. Radio display will show EJECTING DISC when the disc is being ejected and prompt the user to remove the disc.
Page 246: Notes On Playing Mp3/Wma Files
Notes On Playing MP3/WMA Files The radio can play MP3/WMA files; however, acceptable MP3/WMA file recording media and formats are limited. When writing MP3/WMA files, pay attention to the following restrictions. Supported Media (Disc Types) The MP3/WMA file recording media supported by the radio are CDDA, CD-R, CD-RW, MP3,WMA, DVD Video, DVD-R, DVD-RW, DVD+R, DVD+RW, and CDDA+MP3.
Page 247 246 UNDERSTANDING YOUR INSTRUMENT PANEL If a disc contains multi-formats, such as CD audio and MP3/WMA tracks, the radio will only play the MP3/ WMA tracks on that disc. Supported MP3/WMA File Formats The radio will recognize only files with the *.MP3/WMA extension as MP3/WMA files.
Page 248: List Button (Disc Mode For Mp3/Wma Play)
Playback of MP3/WMA Files When a medium containing MP3/WMA data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3/WMA files. Loading times for playback of MP3/WMA files may be affected by the following: •...
Page 249 248 UNDERSTANDING YOUR INSTRUMENT PANEL Press and hold the INFO button again for three seconds to return to elapsed time display. Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack, which allows the user to plug in a portable device such as an MP3/WMA player, cassette player, or microphone and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
Page 250 Operating Instructions — Voice Recognition System (VR) (If Equipped) For the radio, refer to “Voice Recognition System (VR)” in Section 3. For UConnect “Voice Recognition System (VR),” refer to “Hands-Free Communication (UConnect )” in Section 3. Operating Instructions - Hands-Free Phone (UConnect ) (If Equipped) Refer to “Hands-Free Communication (UConnect )”...
Page 251: Sales Code Rer - Multimedia System - If Equipped
250 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE RER — MULTIMEDIA SYSTEM — IF EQUIPPED NOTE: The sales code is located on the lower right side of the unit’s faceplate. The RER Multimedia system contains a radio, Sirius Satellite Radio player, navigation system, CD/DVD player, USB port, 20-gigabyte hard drive (HDD), and the UConnect Hands-Free Bluetooth cellular system.
Page 252: Operating Instructions - Satellite Radio
Other special features include direct tune, music type selections, traffic messaging (optional), easy store presets, parental lockout for VES (if equipped), backup camera display for vehicles equipped with a backup camera, and on some models, a dual display screen operation. Refer to your “Navigation User’s Manual”...
Page 253 252 UNDERSTANDING YOUR INSTRUMENT PANEL 4. Touch the screen where the words “Set Time Zone” are displayed. The time zone selection menu will appear on the screen. 5. Select a time zone by touching the screen where your selection appears. If you do not see a time zone that you want to select, touch the screen where the word “Page”...
Page 254: Satellite Radio - If Equipped (Ren/Req/Rer/Res Radios Only)
4. To move the hour forward, touch the screen where the word “Hour” with the arrow pointing upward is dis- played. To move the hour backward, touch the screen where the word “Hour” with the arrow pointing down- ward is displayed. 5.
Page 255: System Activation
254 UNDERSTANDING YOUR INSTRUMENT PANEL System Activation Sirius Satellite Radio service is pre-activated, and you may begin listening immediately to the one year of audio service that is included with the factory-installed satellite radio system in your vehicle. Sirius will supply a wel- come kit that contains general information, including how to setup your on-line listening account at no addi- tional charge.
Page 256: Selecting Satellite Mode
Selecting Satellite Mode Press the SAT button until SAT appears in the display. A CD may remain in the radio while in the Satellite radio mode. Satellite Antenna To ensure optimum reception, do not place items on the roof around the rooftop antenna location or strap items to the trunk lid around the trunk lid antenna (if equipped).
Page 257 256 UNDERSTANDING YOUR INSTRUMENT PANEL SCAN Button Pressing the SCAN button causes the tuner to search for the next channel, pausing for eight seconds before con- tinuing to the next. To stop the search, press the SCAN button a second time. INFO Button Pressing the INFO button will cycle between Artist, Song Title, and Composer (if available) information.
Page 258: Operating Instructions - Hands-Free Phone (If Equipped)
SETUP Button Pressing the SETUP button allows you to select the following items: • Display Sirius ID number — Press the AUDIO/ SELECT button to display the Sirius ID number. This number is used to activate, deactivate, or change the Sirius subscription.
Page 259: Operating Instructions - Video Entertainment System (Ves ) (If Equipped)
258 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Video Entertainment System (VES ) (If Equipped) Refer to separate “Video Entertainment System (VES ) Guide.” CD/DVD DISC MAINTENANCE To keep the CD/DVD discs in good condition, take the following precautions: 1. Handle the disc by its edge; avoid touching the surface.
Page 260: Climate Controls
CLIMATE CONTROLS Manual Heater Only The controls for the heating/ventilation system in this vehicle consist of a series of rotary knobs. These comfort controls can be set to obtain desired interior conditions. UNDERSTANDING YOUR INSTRUMENT PANEL 259 Mode Control The mode control allows you to choose from several pat- terns of air distribution.
Page 261 260 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: There is a difference in temperature between the upper and lower outlets for added comfort. The warmer air goes to the floor outlets. This feature gives improved comfort during sunny but cool conditions. Floor Air is directed through the floor outlets and side window demist outlets with a small amount through the defrost outlet.
Page 262: Manual Air Conditioning And Heating System - If Equipped
Manual Air Conditioning and Heating System — If Equipped The controls for the heating/air conditioning and venti- lation system in this vehicle consist of a series of rotary knobs. These comfort controls can be set to obtain desired interior conditions. UNDERSTANDING YOUR INSTRUMENT PANEL 261 The instrument panel features four airflow registers.
Page 263 262 UNDERSTANDING YOUR INSTRUMENT PANEL Panel Air is directed through the outlets in the instrument panel. These outlets can be adjusted to direct airflow. Bi-Level Air is directed through the panel and floor outlets. NOTE: There is a difference in temperature between the upper and lower outlets for added comfort.
Page 264 Blower Control Use this control to regulate the amount of air forced through the system in any mode you select. The fan speed increases as you move the control to the right from the OFF position. Temperature Control Use this control to regulate the temperature of the air inside the passenger compartment.
Page 265: Air Conditioning
264 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Continuous use of the “Recirculate” mode may make the inside air stuffy and window fogging may occur. Extended use of this mode is not recommended. In cold or damp weather, the use of the “Recirculate” mode will cause windows to fog on the inside because of moisture buildup inside the vehicle.
Page 266: Operating Tips
MAX A/C For maximum cooling, select ei- ther the Panel or Bi-Level position using the mode control. Then, press the “A/C” and the “Recir- culate” buttons so that both lamps are illuminated, and set the tem- perature control to its coolest set- ting.
Page 267 266 UNDERSTANDING YOUR INSTRUMENT PANEL Regular cleaning of the inside of the windows with a non-filming cleaning solution (vinegar and water works very well) will help prevent contaminates (cigarette smoke, perfumes, etc.) from sticking to the windows. Contaminates increase the rate of window fogging. Summer Operation Air conditioned vehicles must be protected with a high quality antifreeze coolant during summer to provide...
Page 268: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ..... 271 Manual Transmission ....271 Automatic Transmission .
Page 269 268 STARTING AND OPERATING Four–Wheel Drive Operation (Command-Trac™ Or Rock-Trac™) — If Equipped ... . . 285 Operating Instructions/Precautions ..285 Shift Positions ......287 Shifting Procedure .
Page 270 Tire Identification Number (TIN) ..316 Tire Loading And Tire Pressure ... 317 Tires — General Information ....321 Tire Pressure .
Page 271 270 STARTING AND OPERATING Vehicle Loading ......342 Certification Label ..... 342 Trailer Towing .
Page 272: Starting Procedures
STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust both inside and outside mirrors, and fasten your seat belts. WARNING! Do not leave children or animals inside parked vehicles in hot weather. Interior heat buildup may cause serious injury or death. Manual Transmission Apply the parking brake, place the shift lever in NEU- TRAL and depress the clutch pedal before starting ve-...
Page 273: Extreme Cold Weather (Below -20°F Or -29°C)
272 STARTING AND OPERATING Turn the ignition switch to the START position and release when the engine starts. If the engine fails to start within 10 seconds, turn the ignition switch to the LOCK position, wait 10 to 15 seconds, then repeat the normal starting procedure.
Page 274: If Engine Fails To Start
If Engine Fails to Start WARNING! • Never pour fuel or other flammable liquids into the throttle body air inlet opening in an attempt to start the vehicle. This could result in a flash fire causing serious personal injury. • Do not attempt to push or tow your vehicle to get it started.
Page 275: After Starting
274 STARTING AND OPERATING If the engine shows no sign of starting after two 15 second periods of cranking with the accelerator pedal held to the floor, repeat the “Normal Starting” or “Ex- treme Cold Weather” procedures. With Tip Start (Automatic Transmission Only) If the engine fails to start after you have followed the “Normal Starting”...
Page 276: Engine Block Heater - If Equipped
ENGINE BLOCK HEATER — IF EQUIPPED The engine block heater warms engine coolant and permits quicker starts in cold weather. Connect the cord to a standard 110-115 Volt AC electrical outlet with a grounded, three wire extension cord. The engine block heater cord is found under the hood bundled in front of the battery tray.
Page 277: Shifting
276 STARTING AND OPERATING NOTE: During cold weather, you may experience in- creased effort in shifting until the transmission fluid warms up. This is normal. Shift Pattern Shifting Fully depress the clutch pedal before shifting gears. As you release the clutch pedal, lightly depress the accelera- tor pedal.
Page 278: Downshifting
Manual Transmission Shift Speeds in MPH (KM/H) Speeds 1 to 2 2 to 3 3 to 4 4 to 5 5 to 6 gine 3.8L Accel. 15 (24) (39) (55) Cruise 10 (16) (31) (43) Downshifting Moving from a high gear down to a lower gear is recommended to preserve brakes when driving down steep hills.
Page 279: Reverse Shifting
278 STARTING AND OPERATING Maximum Recommended Downshift Speeds CAUTION! Failure to follow the maximum recommended down- shifting speeds may cause the engine to overspeed and/or damage the clutch disc even if the clutch pedal is depressed. Manual Transmission Downshift Speeds in MPH (KM/H) Gear Selec-...
Page 280: Automatic Transmission
AUTOMATIC TRANSMISSION CAUTION! Damage to the transmission may occur if the follow- ing precautions are not observed: • Shift into PARK only after the vehicle has come to a complete stop. • Shift into or out of REVERSE only after the vehicle has come to a complete stop and the engine is at idle speed.
Page 281: Shift Lock Manual Override
280 STARTING AND OPERATING Shift Lock Manual Override Your vehicle may be equipped with a shift lock manual override. The manual override may be used in the event that the shift lever should fail to move from PARK with the key in the ON position and the brake pedal de- pressed.
Page 282: Brake/Transmission Interlock System
Brake/Transmission Interlock System This system prevents you from moving the shift lever out of PARK and into any gear unless the brake pedal is pressed. This system is active only while the ignition switch is in the ON position. Always depress the brake pedal first, before moving the shift lever out of PARK.
Page 283 282 STARTING AND OPERATING PARK This gear position supplements the parking brake by locking the transmission. The engine can be started in this range. Never use PARK while the vehicle is in motion. Apply the parking brake when leaving the vehicle in this range.
Page 284 NOTE: Towing, coasting, or driving the vehicle for any other reason with the shift lever in NEUTRAL can result in severe transmission damage. Refer to “Recreational Towing” in Section 5 and “Towing a Disabled Vehicle” in Section 6 of this manual. OVERDRIVE For most city and highway driving.
Page 285 284 STARTING AND OPERATING Overdrive can be locked out by pressing the O/D OFF switch located on the center console. The O/D OFF indicator light (on the switch) will illuminate to show that the switch has been activated. When the indicator light is on, Overdrive is locked out.
Page 286: Four-Wheel Drive Operation (Command-Trac™ Or Rock-Trac™) - If Equipped
Torque Converter Clutch A feature designed to improve fuel economy has been added to the automatic transmission of this vehicle. A clutch within the torque converter engages automatically at calibrated speeds. This may result in a slightly differ- ent feeling or response during normal operation in high gear.
Page 287 286 STARTING AND OPERATING rear wheels to rotate at the same speed. This is accom- plished by simply moving the shift lever to one of these positions. The 4H and 4L positions are intended for loose, slippery road surfaces only, and not intended for normal driving.
Page 288: Shift Positions
WARNING! You or others could be injured if you leave the vehicle unattended with the transfer case in the N (Neutral) position without first fully engaging the parking brake. The transfer case N (Neutral) position disengages both the front and rear driveshaft from the powertrain, and will allow the vehicle to move regardless of the transmission position.
Page 289: Shifting Procedure
288 STARTING AND OPERATING N (Neutral) Position This range disengages the front and rear driveshafts from the powertrain. To be used for flat towing behind another vehicle. Refer to “Recreational Towing” in Section 5 of this manual. 4L Position This range locks the front and rear driveshafts together, forcing the front and rear wheels to rotate at the same speed.
Page 290: Trac-Lok™ Rear Axle - If Equipped
4H to 4L or 4L to 4H With the vehicle rolling at 2 to 3 mph (3 to 5 km/h), shift an automatic transmission into NEUTRAL (N), or de- press the clutch pedal on a manual transmission. While the vehicle is coasting at 2 to 3 mph (3 to 5 km/h), shift the transfer case lever firmly to the desired position.
Page 291: Axle Lock (Tru-Lok™) - Rubicon Models
290 STARTING AND OPERATING Trac-Lok™ is especially helpful during slippery driving conditions. With both rear wheels on a slippery surface, a slight application of the accelerator will supply maxi- mum traction. WARNING! On vehicles equipped with a limited-slip differen- tial, never run the engine with one rear wheel off the ground.
Page 292: Rear Axle Lock - 4Wd Non-Rubicon Models (If Equipped)
• Vehicle speed should be 10 mph (16 km/h) or less. To activate the system, press the bottom of the AXLE LOCK switch once to lock the rear axle only (the Rear Axle Lock Indicator Light will illuminate), press the bottom of the switch again to lock the front axle (the Front Axle Lock Indicator Light will illuminate).
Page 293: Electronic Sway Bar Disconnect - If Equipped
292 STARTING AND OPERATING The rear axle lock will disengage if the vehicle is taken out of 4L (Low) range, or the ignition switch is turned to the OFF position. ELECTRONIC SWAY BAR DISCONNECT — IF EQUIPPED Your vehicle may be equipped with an electronic discon- necting stabilizer/sway bar.
Page 294 when activation conditions are not met. The stabilizer/ sway bar should remain in on-road mode during normal driving conditions. WARNING! Do not disconnect the stabilizer bar and drive on hard surfaced roads or at speeds above 18 mph (29 km/h), you may lose control of the vehicle, which could result in serious injury.
Page 295: On-Road Driving Tips
294 STARTING AND OPERATING WARNING! If the stabilizer/sway bar will not return to on-road mode, vehicle stability is greatly reduced. Do not attempt to drive vehicle over 18 mph (29 km/h). Driving faster than 18 mph (29 km/h) may cause loss of control of the vehicle, which could result in serious injury.
Page 296 STARTING AND OPERATING 295 2. Remove one bolt from underside of vehicle. 3. Remove side step assembly.
Page 297: The Basics Of Off-Road Driving
296 STARTING AND OPERATING The Basics of Off-Road Driving You will encounter many types of terrain driving off- road. You should be familiar with the terrain and area before proceeding. There are many types of surface conditions: hard packed dirt, gravel, rocks, grass, sand, mud, snow and ice.
Page 298: When To Use 4L (Low) Range
When To Use 4L (Low) Range When off-road driving, shift into 4L (Low) for additional traction and control on slippery or difficult terrain, ascending or descending steep hills, and to increase low speed pulling power. This range should be limited to extreme situations such as deep snow, mud, steep in- clines, or sand where additional low speed pulling power is needed.
Page 299 298 STARTING AND OPERATING Deep mud creates a great deal of suction around the tires and is very difficult to get through. You should use 2nd gear (manual transmission), or DRIVE (automatic trans- mission), with the transfer case in the 4L (Low) position to maintain your momentum.
Page 300: Crossing Obstacles (Rocks And Other High Points)
Crossing Obstacles (Rocks And Other High Points) While driving off-road, you will encounter many types of terrain. These varying types of terrain bring different types of obstacles. Before proceeding, review the path ahead to determine the correct approach and your ability to safely recover the vehicle if something goes wrong.
Page 301 300 STARTING AND OPERATING CAUTION! Never attempt to straddle a rock that is large enough to strike your axles or undercarriage. CAUTION! Never attempt to drive over a rock which is large enough to contact the door sills. Crossing A Ravine, Gully, Ditch, Washout Or Rut When crossing a ravine, gully, ditch, washout or a large rut, the angled approach is the key to maintaining your vehicle’s mobility.
Page 302: Hill Climbing
accelerator to avoid spinning the log out from under your tires. Then ease the vehicle off the log using your brakes. CAUTION! Do not attempted to cross a log with a greater diameter than the running ground clearance or the vehicle will become high centered.
Page 303 302 STARTING AND OPERATING branches or other obstacles on the path? Can you safely recover the vehicle if something goes wrong? If every- thing looks good and you feel confident, shift the trans- mission into a lower gear with 4L (Low) engaged, and proceed with caution maintaining your momentum as you climb the hill.
Page 304 descent? Is there plenty of distance at the base of the hill to regain control if the vehicle descends to fast? If you feel confident in your ability to proceed then make sure you are in 4L (Low) and proceed with caution. Allow engine braking to control the descent and apply your brakes if necessary, but do not allow the tires to lock.
Page 305: Driving Through Water
304 STARTING AND OPERATING WARNING! If the engine stalls or you lose headway or cannot make it to the top of a steep hill or grade, never attempt to turn around. To do so may result in tipping and rolling the vehicle, which may result in severe injury.
Page 306 CAUTION! Water ingestion into the axles, transmission, transfer case, engine or vehicle interior can occur if you drive too fast or through too deep of water. Water can cause permanent damage to engine, driveline or other vehicle components and your brakes will be less effective once wet and/or muddy.
Page 307 306 STARTING AND OPERATING CAUTION! Muddy waters can reduce the cooling system effec- tiveness by depositing debris onto the radiator. Crossing Ditches, Streams, Shallow Rivers Or Other Flowing Water Flowing water can be extremely dangerous. Never at- tempt to cross a fast running stream or river even in shallow water.
Page 308: After Driving Off-Road
After Driving Off-Road Off-road operation puts more stress on your vehicle than does most on-road driving. After going off-road it is always a good idea to check for damage. That way you can get any problems taken care of right away and have your vehicle ready when you need it.
Page 309: Parking Brake
308 STARTING AND OPERATING PARKING BRAKE To set the parking brake, pull the lever up as firmly as possible. When the parking brake is applied with the ignition ON, the Brake Warning Light in the instrument cluster will light. To release the parking brake, pull up slightly, press the center button, then lower the lever completely.
Page 310: Anti-Lock Brake System
the load on the transmission locking mechanism may make it difficult to move the shifter out of PARK. WARNING! • Always fully apply the parking brake when leav- ing your vehicle, or it may roll and cause damage or injury. Also, be certain to leave an automatic transmission in PARK, a manual transmission in REVERSE or 1st gear.
Page 311 310 STARTING AND OPERATING WARNING! Significant over or under-inflation of tires, or mixing sizes of tires or wheels on the vehicle can lead to loss of braking effectiveness. The Anti-Lock Brake System conducts a low speed self- test at about 12 mph (20 km/h). If for any reason, your foot is on the brake when the vehicle reaches 12 mph (20 km/h), this check will be delayed until 25 mph (40 km/h).
Page 312: Power Steering
WARNING! • Anti-Lock Brake Systems (ABS) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase braking or steering efficiency beyond that afforded by the condition of the vehicle brakes and tires or the traction afforded.
Page 313 312 STARTING AND OPERATING If for some reason the power assist is interrupted, it will still be possible to steer your vehicle. Under these condi- tions, you will observe a substantial increase in steering effort, especially at very low vehicle speeds and during parking maneuvers.
Page 314: Tire Safety Information
TIRE SAFETY INFORMATION Tire Markings NOTE: • P(Passenger)-Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designation. Ex- ample: P215/65R15 95H. STARTING AND OPERATING 313 • European Metric tire sizing is based on European design standards.
Page 315 314 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary Spare tire 31 = Overall Diameter in Inches (in) 215 = Section Width in Millimeters (mm)
Page 316 Service Description: 95 = Load Index —A numerical code associated with the maximum load a tire can carry H = Speed Symbol —A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —The maximum speed corresponding to the Speed Symbol should only be achieved un- der specified operating conditions (ie., tire pressure, vehicle loading, road conditions and posted speed limits)
Page 317: Tire Identification Number (Tin)
316 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire however the date code may only be on one side. Tires with white sidewalls will have the full TIN including date code DOT = Department of Transportation —This symbol certifies that the tire is in compliance with the U.S.
Page 318: Tire Loading And Tire Pressure
STARTING AND OPERATING 317 Tire Loading and Tire Pressure Tire Placard Location Tire Placard Location (Four-Door Models) Tire Placard Location (Two-Door Models)
Page 319 318 STARTING AND OPERATING Tire and Loading Information Placard Tire And Loading Information Placard This placard tells you important information about 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry 3) tire size designed for your vehicle 4) cold tire inflation pressures for the front, rear and spare tires.
Page 320 lbs.” on the Tire and Loading Information placard. The combined weight of occupants, cargo/luggage and trailer tongue weight (if applicable) should never exceed the weight referenced here. Steps for Determining Correct Load Limit 1. Locate the statement “The combined weight of occu- pants and cargo should never exceed XXX pounds”...
Page 321 320 STARTING AND OPERATING...
Page 322: Tires - General Information
WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 323: Tire Inflation Pressures
322 STARTING AND OPERATING Economy Tire Inflation Pressures Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Under-inflation also increases tire rolling resistance and results in higher fuel consump- tion.
Page 324 Tire Placard Location (Four-Door Models) Tire pressure should be checked and adjusted as well as inspecting for signs of tire wear or visible damage, at least once a month. Use a good quality pocket-type gauge to check tire pressure. Do not make a visual judgement when determining proper inflation.
Page 325: Tire Pressures For High-Speed Operation
324 STARTING AND OPERATING Tire pressures change by approximately 1 psi (7 kPa) per 12° F (7° C) of air temperature change. Keep this in mind when checking tire pressure inside a garage especially in the winter. Example: If garage temperature = 68° F (20° C) and the outside temperature = 32°...
Page 326: Radial-Ply Tires
Radial-Ply Tires WARNING! Combining radial ply tires with other types of tires on your vehicle will cause your vehicle to handle poorly. The instability could cause an accident. Al- ways use radial tires in sets of four. Never combine them with other types of tires. Cuts and punctures in radial tires are repairable only in the tread area because of sidewall flexing.
Page 327: Tread Wear Indicators
326 STARTING AND OPERATING Tread Wear Indicators Tread wear indicators are in the original equipment tires to help you in determining when your tires should be replaced. These indicators are molded into the bottom of the tread grooves and will appear as bands when the tread depth becomes 1/16 inch (2 mm).
Page 328: Replacement Tires
WARNING! Tires and spare tire should be replaced after six years, regardless of the remaining tread. Failure to follow this warning can result in sudden tire failure. You could lose control and have an accident resulting in serious injury or death. Keep unmounted tires in a cool, dry place with as little exposure to light as possible.
Page 329: Alignment And Balance
328 STARTING AND OPERATING WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change suspension dimensions and performance characteristics, result- ing in changes to steering, handling, and braking of your vehicle.
Page 330: Tire Chains
Improper alignment will not cause vehicle vibration. Vibration may be a result of tire and wheel out-of- balance. Proper balancing will reduce vibration and avoid tire cupping and spotty wear. TIRE CHAINS Install chains on rear tires only. Tire chains may be installed on all models except the Sahara and Rubicon.
Page 331: Tire Pressure Monitor System (Tpms)
330 STARTING AND OPERATING Follow the recommended tire rotation frequency for your type of driving. Refer to the “Maintenance Schedule” in Section 8 of this manual. More frequent rotation is permissible if desired. The reasons for any rapid or unusual wear should be corrected prior to rotation being performed.
Page 332 The TPMS will warn the driver of a low tire pressure if the tire pressure falls below the low pressure warning threshold for any reason, including low temperature effects, or natural pressure loss through the tire. The TPMS will continue to warn the driver of low tire pressure as long as the condition exists, and will not turn off until the tire pressure is at or above recommended cold placard pressure.
Page 333 332 STARTING AND OPERATING CAUTION! The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures have been established for the tire size equipped on your vehicle. Undesirable system operation or sensor damage may result when using replacement equip- ment that is not of the same size, type, and/or style.
Page 334: Base System
• The TPMS is not a substitute for proper tire mainte- nance, and it is the driver’s responsibility to maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the Tire Pressure Monitoring Telltale Light. •...
Page 335 334 STARTING AND OPERATING inflation pressure of each tire on your vehicle, and inflate each tire to the vehicle’s recommended cold placard pressure value. The system will automatically update and the Tire Pressure Monitoring Telltale Light will extinguish once the updated tire pressures have been received.
Page 336: General Information
NOTE: If your vehicle is not equipped with a matching full-size spare wheel and tire assembly, it does not have a tire pressure monitoring sensor in the spare tire. The TPMS will not be able to monitor the tire pressure. If you install the spare tire in place of a road tire that has a pressure below the low-pressure warning limit, upon the next ignition key cycle, a chime will sound and the Tire...
Page 337: Fuel Requirements
336 STARTING AND OPERATING FUEL REQUIREMENTS All engines (except 5.7L engines) are de- signed to meet all emissions regulations and provide excellent fuel economy and performance when using high quality un- leaded “regular” gasoline having an oc- tane rating of 87. The use of premium gasoline is not recommended.
Page 338: Gasoline/Oxygenate Blends
The manufacturer supports the use of reformulated gaso- line. Properly blended reformulated gasoline will pro- vide excellent performance and durability for the engine and fuel system components. Gasoline/Oxygenate Blends Some fuel suppliers blend unleaded gasoline with oxy- genates such as 10% ethanol, MTBE, and ETBE. Oxygen- ates are required in some areas of the country during the winter months to reduce carbon monoxide emissions.
Page 339: Materials Added To Fuel
338 STARTING AND OPERATING It is even more important to look for gasoline without MMT in Canada, because MMT can be used at levels higher than those allowed in the United States. prohibited Federal reformulated gasoline. Materials Added To Fuel All gasoline sold in the United States is required to contain effective detergent additives.
Page 340: Carbon Monoxide Warnings
• The use of fuel additives which are now being sold as octane enhancers is not recommended. Most of these products contain high concentrations of methanol. Fuel system damage or vehicle performance problems resulting from the use of such fuels or additives is not the responsibility of the manufacturer.
Page 341: Adding Fuel
340 STARTING AND OPERATING ADDING FUEL Fuel Filler Cap (Gas Cap) The gas cap is located on the driver’s side of the vehicle. If the gas cap is lost or damaged, be sure the replacement cap is the correct one for this vehicle. Fuel Filler Cap Loose Fuel Filler Cap Message (gASCAP) After fuel has been added, the vehicle diagnostic system...
Page 342 CAUTION! Damage to the fuel system or emission control sys- tem could result from using an improper fuel cap (gas cap). A poorly fitting cap could let impurities into the fuel system. Also, a poorly fitting after- market cap can cause the Malfunction Indicator Light to illuminate, due to fuel vapors escaping from the system.
Page 343: Vehicle Loading
342 STARTING AND OPERATING WARNING! A fire may result if gasoline is pumped into a portable container that is inside of a vehicle. You could be burned. Always place gas containers on the ground while filling. VEHICLE LOADING Certification Label As required by National Highway Traffic Safety Admin- istration regulations, your vehicle has a certification label affixed to the driver’s side door or B-Pillar.
Page 344 Each axle’s GAWR is determined by the components in the system with the lowest load carrying capacity (axle, springs, tires, or wheels). Heavier axles or suspension components, sometimes specified by purchasers for in- creased durability, does not necessarily increase the ve- hicle’s GVWR.
Page 345: Trailer Towing
344 STARTING AND OPERATING the front or rear axles has been exceeded, but the total load is within the specified GVWR. If so, weight must be shifted from front to rear, or rear to front, as appropriate until the specified weight limitations are met. Store the heavier items down low and be sure that the weight is distributed equally.
Page 346: Common Towing Definitions
Common Towing Definitions The following trailer towing-related definitions will as- sist you in understanding the following information: Gross Vehicle Weight Rating (GVWR) The GVWR is the total allowable weight of your vehicle. This includes driver, passengers, cargo and trailer tongue weight.
Page 347 346 STARTING AND OPERATING Trailer Tongue Weight (TW) The trailer tongue weight is the downward force exerted on the hitch ball by the trailer. In most cases it should not be less than 10% or more than 15% of the trailer load. You must consider this as part of the load on your vehicle.
Page 348 STARTING AND OPERATING 347 WARNING! An improperly adjusted weight-distributing hitch system may reduce handling, stability, braking per- formance, and could result in an accident. Weight-Distributing Hitch Systems may not be com- patible with Surge Brake Couplers. Consult with your hitch and trailer manufacturer or a reputable Recreational Vehicle dealer...
Page 349: Trailer Hitch Classification
348 STARTING AND OPERATING Improper Adjustment of Weight-Distributing System Trailer Hitch Classification The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition.
Page 350 Engine/ Axle Transmission 3.8L/Manual 3.21 Model (4WD) 3.8L/Manual 3.73 Model (4WD) 3.8L/ 3.73 Automatic Model (4WD) 3.8L/Manual 3.21 2–Door Sahara Model (4WD) 3.8L/Manual 3.73 2–Door Sahara Model (4WD) 3.8L/ 3.73 2–Door Sahara Automatic Model (4WD) 3.8L/Manual 4.10 2–Door Rubi- con Model Model GCWR (Gross Frontal Area...
Page 351 350 STARTING AND OPERATING 3.8L/ 4.10 Automatic 3.8L/Manual 3.21 3.8L/Manual 3.73 3.8L/ 3.73 Automatic 3.8L/Manual 3.21 3.8L/Manual 3.73 3.8L/ 3.73 Automatic 3.8L/Manual 3.21 3.8L/Manual 3.73 2–Door Rubi- 6,281 lbs con Model (2 849 kg) (4WD) 4–Door X 5,121 lbs Model (2WD) (2 323 kg) 4–Door X 7,621 lbs...
Page 352 3.8L/ 3.73 Automatic Model (4WD) 3.8L/Manual 3.21 4–Door Sahara Model (4WD) 3.8L/Manual 3.73 4–Door Sahara Model (4WD) 3.8L/ 3.73 4–Door Sahara Automatic Model (4WD) 3.8L/Manual 4.10 4–Door Rubi- 3.8L/ 4.10 4–Door Rubi- Automatic Refer to local laws for maximum trailer towing speeds. NOTE: The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and should never exceed the weight referenced on the Tire...
Page 353: Trailer And Trailer Tongue Weight
352 STARTING AND OPERATING Trailer and Trailer Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle.
Page 354: Towing Requirements
NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory-installed options, or authorized dealer-installed options, must be considered as part of the total load on your vehicle. Refer to the Tire and Loading Information placard in the “Tire Safety Information”...
Page 355 354 STARTING AND OPERATING WARNING! Improper towing can lead to an injury accident. Follow these guidelines to make your trailer towing as safe as possible: Make certain that the load is secured in the trailer and will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts can occur that may be difficult for the driver to control.
Page 356 2. GTW 3. GAWR 4. Tongue weight rating for the trailer hitch utilized (This requirement may limit the ability to always achieve the 10% to 15% range of tongue weight as a percentage of total trailer weight). Towing Requirements — Tires −...
Page 357 356 STARTING AND OPERATING − An electronically-actuated trailer brake controller is required when towing a trailer with electronically actuated brakes. When towing a trailer equipped with a hydraulic surge-actuated brake system, an electronic brake controller is not required. − Trailer brakes are recommended for trailers over 1,000 lbs (454 kg) and required for trailers in excess of 2,000 lbs (907 kg).
Page 358: Towing Tips
The Trailer Tow Package will include a 4–pin wiring harness. Use a factory-approved trailer harness and connector. NOTE: Do not cut or splice wiring into the vehicles wiring harness. The electrical connections are all complete to the vehicle but you must mate the harness to a trailer connector. Refer to the following illustration.
Page 359 358 STARTING AND OPERATING If using a manual transmission vehicle for trailer towing, all starts must be in 1st gear to avoid excessive clutch slippage. Towing Tips — Automatic Transmission The DRIVE range can be selected when towing. How- ever, if frequent shifting occurs while in this range, the OVERDRIVE range should be selected.
Page 360: Recreational Towing (Behind Motorhome, Etc.)
Towing Tips — Cooling System To reduce potential for engine and transmission over- heating, take the following actions: − Highway Driving Reduce speed. − Air Conditioning Turn off temporarily. − refer to Cooling System Operating information in the Maintenance section of this manual for more informa- tion.
Page 361: Towing - 4Wd Models
360 STARTING AND OPERATING Towing – 4WD Models NOTE: The transfer case must be shifted into N (Neu- tral) for recreational towing. Shifting Into Neutral (N) Use the following procedure to prepare your vehicle for recreational towing. CAUTION! It is necessary to follow these steps to be certain that the transfer case is fully in N (Neutral) before recre- ational towing to prevent damage to internal parts.
Page 362 CAUTION! Damage to the transmission may occur if the trans- mission is shifted into PARK with the transfer case in N (Neutral) and the engine running. With the trans- fer case in N (Neutral) ensure that the engine is off prior to shifting the transmission into PARK (refer to steps 7 –...
Page 363 362 STARTING AND OPERATING CAUTION! • Do not use a bumper-mounted clamp-on tow bar on your vehicle. The bumper face bar will be damaged.
Page 364: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flashers ....364 If Your Engine Overheats ....365 Jacking And Tire Changing .
Page 365: Hazard Warning Flashers
364 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHERS Your vehicle’s hazard warning flasher is an emergency warning system. When you activate it, all front and rear directional signals will flash intermittently. Use it when your vehicle is disabled on or near the road. It warns other drivers to steer clear of you and your vehicle.
Page 366: If Your Engine Overheats
IF YOUR ENGINE OVERHEATS In any of the following situations, you can reduce the potential for overheating by taking the appropriate ac- tion. • On the highways — Slow down. • In city traffic — While stopped, shift transmission into NEUTRAL, but do not increase engine idle speed.
Page 367: Jacking And Tire Changing
366 WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING WARNING! • Getting under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed. Never get any part of your body under a vehicle that is on a jack.
Page 368: Spare Tire Stowage
Spare Tire Stowage To remove the spare tire from the carrier, remove the tire cover, if equipped, and remove the lug nuts with the lug wrench turning them counterclockwise. NOTE: If you have added aftermarket accessories to the spare tire mounted carrier, it cannot exceed a gross weight of 50 lbs (23 kg) including the weight of the spare tire.
Page 369: Jacking Instructions
368 WHAT TO DO IN EMERGENCIES Jacking Instructions Jack Warning Label WARNING! Carefully follow these tire changing warnings to help prevent personal injury or damage to your vehicle: • Always park on a firm, level surface as far from the edge of the roadway as possible before raising the vehicle.
Page 370 1. Remove spare tire, jack and tools from stored location. 2. Loosen (but do not remove) the wheel lug nuts by turning them to the left one turn while the wheel is still on the ground. 3. Assemble the jack and jacking tools. Connect jack handle driver to extension, then to lug wrench.
Page 371 370 WHAT TO DO IN EMERGENCIES WARNING! Raising the vehicle higher than necessary can make the vehicle less stable and cause an accident. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire. 6.
Page 372: Jump Starting
JUMP STARTING If the vehicle has a discharged battery, booster cables may be used to obtain a start from a booster battery or the battery in another vehicle. This type of start can be dangerous if done improperly, so follow this procedure carefully.
Page 373 372 WHAT TO DO IN EMERGENCIES 2. Park the booster vehicle within cable reach but with- out letting the vehicles touch. Set the parking brake on both vehicles, shift the automatic transmission into PARK, or the manual transmission into NEUTRAL, and turn the ignition OFF.
Page 374 WARNING! Any procedure other than above could result in: 1. Personal injury caused by electrolyte squirting out the battery vent; 2. Personal injury or property damage due to battery explosion; 3. Damage to charging system of booster vehicle or of immobilized vehicle. WHAT TO DO IN EMERGENCIES 373 WARNING! •...
Page 375: Emergency Tow Hooks - If Equipped
374 WHAT TO DO IN EMERGENCIES EMERGENCY TOW HOOKS — IF EQUIPPED If your vehicle is equipped with tow hooks, they are mounted in the front and the rear. CAUTION! Tow hooks are for emergency use only, to rescue a vehicle stranded off road.
Page 376: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment – 3.8L ....378 Onboard Diagnostic System — OBD II ..379 Loose Fuel Filler Cap Message ... . 380 Emissions Inspection And Maintenance Programs .
Page 377 376 MAINTAINING YOUR VEHICLE Driveline And Steering Component Lubrication ......392 Body Lubrication ..... 392 Windshield Wiper Blades .
Page 378 Center High-Mounted Stop Light (CHMSL) . . . 423 Fluid Capacities ......424 Fluids, Lubricants And Genuine Parts ..424 MAINTAINING YOUR VEHICLE 377 Engine .
Page 379: Engine Compartment - 3.8L
378 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT – 3.8L...
Page 380: Onboard Diagnostic System - Obd Ii
ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 381: Loose Fuel Filler Cap Message
380 MAINTAINING YOUR VEHICLE Loose Fuel Filler Cap Message After fuel is added, the vehicle diagnostic system can determine if the fuel filler cap is possibly loose, improp- erly installed, or damaged. A “gASCAP” message will be displayed in the odometer. Tighten the gas cap until a clicking sound is heard.
Page 382 Your vehicle has a simple ignition key-actuated test, which you can use prior to going to the test station. To check if your vehicle’s OBD II system is ready, you must do the following: 1. Insert your ignition key into the ignition switch. 2.
Page 383: Replacement Parts
382 MAINTAINING YOUR VEHICLE serviced before going to the I/M station. The I/M station can fail your vehicle because the MIL is on with the engine running. REPLACEMENT PARTS Use of genuine MOPAR parts for normal/scheduled maintenance and repairs is highly recommended to en- sure the designed performance.
Page 384: Maintenance Procedures
MAINTENANCE PROCEDURES The pages that follow contain the required maintenance services determined by the engineers who designed your vehicle. Besides the maintenance items for which there are fixed maintenance intervals, there are other items that should operate satisfactorily without periodic maintenance. However, if a malfunction of these items does occur, it could adversely affect the engine or vehicle performance.
Page 385 384 MAINTAINING YOUR VEHICLE CAUTION! Overfilling or underfilling the crankcase will cause aeration or loss of oil pressure. This could damage your engine. Change Engine Oil Refer to the Maintenance Schedule in Section 8 for recommended engine oil change intervals. Engine Oil Selection For best performance and maximum protection for all engines under all types of operating conditions, the...
Page 386 Lubricants which do not have both, the engine oil certi- fication mark and the correct SAE viscosity grade num- ber, should not be used. Synthetic Engine Oils Synthetic engine oils can be used if the recommended oil quality requirements are met, and the recommended maintenance intervals for oil and filter changes are followed.
Page 387: Drive Belts - Check Condition And Tension
386 MAINTAINING YOUR VEHICLE Drive Belts — Check Condition and Tension Belt tension is controlled by means of an automatic tensioner. No belt tension adjustments are required. However, belt and belt tensioner condition should be inspected at the specified intervals, and replaced if re- quired.
Page 388 CAUTION! Damage to the catalytic converter can result if your vehicle is not kept in proper operating condition. In the event of engine malfunction, particularly involv- ing engine misfire or other apparent loss of perfor- mance, have your vehicle serviced promptly. Contin- ued operation of your vehicle with a severe malfunction could cause the converter to overheat, resulting in possible damage to the converter and...
Page 389: Crankcase Emission Control System
388 MAINTAINING YOUR VEHICLE To minimize the possibility of catalytic converter dam- age: • Do not shut off the engine or interrupt the ignition when the transmission is in gear and the vehicle is in motion. • Do not try to start the engine by pushing or towing the vehicle.
Page 390: Engine Air Cleaner Filter
Engine Air Cleaner Filter Refer to the Maintenance Schedule in Section 8 for recommended engine air cleaner filter change intervals. WARNING! The air cleaner can provide protection in the case of engine backfire. Do not remove the air cleaner unless it is necessary for repair or maintenance.
Page 391: Air Conditioner Maintenance
390 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance For best possible performance, your air conditioner should be checked and serviced by an authorized dealer at the start of each warm season. This service should include cleaning of the condenser fins and a performance test.
Page 392: Power Steering Fluid Check
NOTE: Use only manufacturer approved A/C System Sealers, Stop Leak Products, Seal Conditioners, Compres- sor Oil, and Refrigerants. Refrigerant Recovery and Recycling R-134a Air Conditioning Refrigerant is a hydrofluoro- carbon (HFC) that is endorsed by the Environmental Protection Agency (EPA) and is an ozone-saving product. However, the manufacturer recommends that air condi- tioning service be performed by authorized dealers or other service facilities using recovery and recycling...
Page 393: Driveline And Steering Component Lubrication
392 MAINTAINING YOUR VEHICLE Driveline And Steering Component Lubrication All driveline and steering components are sealed and do not require lubrication. Driveshafts are not serviceable. Body Lubrication Locks and all body pivot points, including such items as seat tracks, doors, tailgate and hood hinges, should be lubricated periodically to assure quiet, easy operation and to protect against rust and wear.
Page 394: Windshield And Rear Window Washers
Windshield And Rear Window Washers The fluid reservoir for the windshield washers and the rear window washer (if equipped) is shared. The fluid reservoir is located in the engine compartment. Be sure to check the fluid level at regular intervals. Fill the reservoir with windshield washer solvent only (not radiator anti- freeze).
Page 395: Cooling System
394 MAINTAINING YOUR VEHICLE into the passenger compartment. In addition, inspect the exhaust system each time the vehicle is raised for lubri- cation or oil change. Replace as required. Cooling System WARNING! You or others can be badly burned by hot antifreeze/ coolant or steam from your radiator.
Page 396 Cooling System — Drain, Flush, And Refill The cooling system should be drained, flushed, and refilled, at the intervals shown on the Maintenance Schedule. Refer to Section 8 of this manual. If the solution is dirty and contains a considerable amount of sediment, clean and flush with reliable cooling system cleaner.
Page 397 396 MAINTAINING YOUR VEHICLE Adding Engine Coolant Your vehicle has been built with an improved antifreeze/ coolant that allows extended maintenance intervals. This antifreeze/coolant can be used up to 5 Years or 100,000 mi (160 000 km) before replacement. To prevent reducing this extended maintenance period, it is important that you use the same antifreeze/coolant throughout the life of your vehicle.
Page 398 The cap should be inspected and cleaned if there is any accumulation of foreign material on the sealing surfaces. WARNING! The warning words DO NOT OPEN HOT on the cooling system pressure cap are a safety precaution. Never add antifreeze/coolant when the engine is overheated.
Page 399 398 MAINTAINING YOUR VEHICLE When additional antifreeze/coolant is needed to main- tain the proper level, it should be added to the coolant bottle. Do not overfill. Points To Remember NOTE: When the vehicle is stopped after a few miles of operation, you may observe vapor coming from the front of the engine compartment.
Page 400: Hoses And Vacuum/Vapor Harnesses
ONLY the correct type thermostat. Other designs may result in unsatisfactory cooling performance, poor gas mileage, and increased emissions. Hoses and Vacuum/Vapor Harnesses Inspect surfaces of hoses and nylon tubing for evidence of heat and mechanical damage. Hard or soft spots, brittle rubber, cracking, tears, cuts, abrasions, and exces- sive swelling indicate deterioration of the rubber.
Page 401 400 MAINTAINING YOUR VEHICLE Brake and Power Steering System Hoses When servicing the vehicle for scheduled maintenance, inspect surface of hoses for evidence of heat and me- chanical damage. Hard and brittle rubber, cracking, tears, cuts, abrasion, and excessive swelling suggest deteriora- tion of the rubber.
Page 402: Automatic Transmission
Use only brake fluid that has been in a tightly closed container to avoid contamination from foreign matter or moisture. CAUTION! Do not allow petroleum base fluid to contaminate the brake fluid. Seal damage will result. Automatic Transmission Selection of Lubricant It is important that the proper lubricant is used in the transmission to assure optimum transmission perfor- mance.
Page 403 402 MAINTAINING YOUR VEHICLE To properly check the automatic transmission fluid level, the following procedure must be used: 1. Operate the engine at idle speed and normal operating temperature. 2. The vehicle must be on level ground. 3. Fully apply parking brake. 4.
Page 404: Hydraulic Clutch Fluid - Manual
CAUTION! Be aware that if the fluid temperature is below 50° F (10° C), it may not register on the dipstick. Do not add fluid until the temperature is elevated enough to produce an accurate reading. 7. Check for leaks. Release the parking brake. NOTE: To prevent dirt and water from entering the transmission after checking or replenishing fluid, make certain that the dipstick cap is properly reseated.
Page 405: Transfer Case
404 MAINTAINING YOUR VEHICLE Fluid Level Check Check the fluid level by removing the fill plug. The fluid level should be between the bottom of the fill hole and a point not more than 3/16 in (4.76 mm) below the bottom of the hole.
Page 406: Front/Rear Axle Fluid
Drain First remove fill plug (B), then drain plug (C). Recom- mended tightening torque for drain and fill plugs is 15 to 25 ft lbs (20 to 34 N·m). CAUTION! When replacing plugs, do not overtighten. You could damage them and cause them to leak. Selection of Lubricant Use only manufacturer’s recommended fluid.
Page 407: Appearance Care And Protection From Corrosion
406 MAINTAINING YOUR VEHICLE Following off-road usage, completely inspect the under- body of your vehicle. Check tires, body structure, steer- ing, suspension and exhaust system for damage. Check threaded fasteners for looseness, particularly on the chassis, drivetrain components, steering and suspension. Retighten, if required, to torque values specified in the Service Manual.
Page 408 hot or cold weather and other extreme conditions will have an adverse effect on paint, metal trim, and under- body protection. The following maintenance recommendations will enable you to obtain maximum benefit from the corrosion resistance built into your vehicle. What Causes Corrosion? Corrosion is the result of deterioration or removal of paint and protective coatings from your vehicle.
Page 409 408 MAINTAINING YOUR VEHICLE CAUTION! • Do not use abrasive or strong cleaning materials such as steel wool or scouring powder, which will scratch metal and painted surfaces. • Use of power washers exceeding 1,200 psi (8 274 kPa) can result in damage or removal of paint and decals.
Page 410 Wheel and Wheel Trim Care All wheels and wheel trim, especially aluminum and chrome plated wheels should be cleaned regularly with a mild soap and water to prevent corrosion. To remove heavy soil, use MOPAR Wheel Cleaner or select a nonabrasive, non-acidic cleaner.
Page 411 410 MAINTAINING YOUR VEHICLE WARNING! Do not use volatile solvents for cleaning purposes. Many are potentially flammable, and if used in closed areas they may cause respiratory harm. CAUTION! When installing hanging air fresheners in your ve- hicle, read the installation instructions carefully. Some air fresheners will damage the finish of painted or decorated parts if allowed to directly contact any surface.
Page 412 Seat Belt Maintenance Do not bleach, dye or clean the belts with chemical solvents or abrasive cleaners. This will weaken the fabric. Sun damage will also weaken the fabric. If the belts need cleaning, use MOPAR Total Clean, a mild soap solution, or lukewarm water. Do not remove the belts from the vehicle to wash them.
Page 413 MOPAR Jeep Soft Glass Window Cleaner will safely clean all plastic windows without scratching. Removes fine scratches to improve visibility and provide UV protection to help prevent yellowing.
Page 414: Fuses (Totally Integrated Power Module)
zipper halves with fresh water and allow to dry. Aggres- sively work the MOPAR Soft Top Zipper Cleaner and Lubricant into the zipper teeth. If a stuck zipper slide is experienced, work the MOPAR Soft Top Zipper Cleaner and Lubricant into the zipper slide. Several applications may be required before the zipper comes free.
Page 415 414 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 25 Amp Driver Door Node Natural 25 Amp Passenger Door Node Natural 40 Amp Anti-Lock Brake System Green (ABS) Pump Feed/ESP 30 Amp Anti-Lock Brake System Pink (ABS) Valve Feed/ESP — —...
Page 416 Cavity Cartridge Mini Fuse Fuse 20 Amp Front/Rear Washer Yellow — Spare 15 Amp Center High-Mounted Blue Stop Light (CHMSL)/ Switch Stop Lamp Feed 20 Amp Relay Trailer Lighting Yellow (Stop) 20 Amp Frt/Rear Axle Locker Yellow Relay — — —...
Page 417 416 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 10 Amp (Ignition Off Draw) IOD-HVAC/ATC, MW SENSR, Underhood Lamp (UH LMP) 30 Amp Amplifier (AMP) Green 20 Amp Ignition Off Draw— Yellow Cabin Compartment Node (IOD-CCN), Wireless Control Mod- ule (WCM), SIREN, Multifunction Control Switch (MULTIFCTN 20 Amp...
Page 418 Cavity Cartridge Mini Fuse Fuse 10 Amp Occupant Restraint Controller (ORC) 15 Amp Left Tail/License/Park Blue Lamp (LT-TAIL/LIC/ PRK LMP) 15 Amp Right Tail/Park/Run Blue Lamp (RT-TAIL/PRK/ RUN LMP) 25 Amp Auto Shut Down (ASD Natural #1 and #2) 15 Amp Cabin Compartment Blue Node Interior Light...
Page 419 418 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 15 Amp Wiper Motor Frt, J1962 Blue Diagnostic Feed 20 Amp Backup Lamps (B/U Yellow LAMPS) 10 Amp Occupant Restraint Controller (ORC), TT EUROPE 10 Amp Next Generation Con- troller (NGC), Global Powertrain Engine Controller (GPEC) 10 Amp...
Page 420: Vehicle Storage
CAUTION! • When installing the Integrated Power Module cover, it is important to ensure the cover is prop- erly positioned and fully latched. Failure to do so may allow water to get into the Integrated Power Module, and possibly result in an electrical system failure.
Page 421: Replacement Bulbs - If Equipped
420 MAINTAINING YOUR VEHICLE REPLACEMENT BULBS — IF EQUIPPED Interior Lights Auto. Trans. Indicator Light ....658 Courtesy Lights, Under Dash (1)....906 Heater Control Lights (2) .
Page 422: Front Park/Turn Signal
4. Turn both park and turn signal socket assemblies 1/4 turn counterclockwise and remove. 5. Remove the four screws holding the metal retaining ring. 6. Remove the lamp from the collar. 7. Grasp the bulb and turn 1/4 turn counterclockwise. 8.
Page 423: Front Side Marker
422 MAINTAINING YOUR VEHICLE 3. Turn the socket assembly 1/4 turn counterclockwise and remove from housing. Pull the bulb straight from the socket to replace. Front Side Marker 1. Reach under the front fender flare and locate the front side marker socket. 2.
Page 424 2. Separate the housing from the body by pushing the lamp inboard while pulling the lamp away from the body. 3. Rotate the appropriate socket 1/4 turn counterclock- wise, then remove it from the housing. MAINTAINING YOUR VEHICLE 423 4. Pull the bulb straight from the socket to replace. Center High-Mounted Stop Light (CHMSL) The stop lamp is mounted on a bracket that extends upward from the tailgate behind the spare tire.
Page 425 424 MAINTAINING YOUR VEHICLE FLUID CAPACITIES Fuel (Approximate) — 2–Door Models Fuel (Approximate) — 4–Door Models Engine Oil with Filter 3.8 Liter Engine (SAE 5W-20, API Certified Engine Oil) Cooling System * 3.8 Liter Engine (MOPAR Antifreeze/Engine Coolant 5 Year/ 100,000 Mile Formula) * Includes heater and coolant recovery bottle filled to MAX level.
Page 426 FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Engine Coolant Engine Oil Spark Plugs (3.8L Engine) Oil Filter (3.8L Engine) Fuel Selection Fluid, Lubricant, or Genuine Part MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) Use API Certified SAE 5W-20 Engine Oil, meeting the requirements of DaimlerChrysler Material Standard MS-6395.
Page 427 426 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transmission Manual Transmission Transfer Case Axle Differential (Front) Axle Differential (Rear) Brake Master Cylinder Power Steering Reservoir Fluid, Lubricant, or Genuine Part MOPAR ATF+4 Automatic Transmission Fluid MOPAR Manual Transmission Lubricant or equivalent (meeting the require- ments of DaimlerChrysler Material Standard MS-9224) MOPAR ATF+4 Automatic Transmission Fluid or equivalent.
Page 428 MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance ..428 Maintenance Schedule ....428 Required Maintenance Intervals ... 431...
Page 429 428 MAINTENANCE SCHEDULES EMISSIONS CONTROL SYSTEM MAINTENANCE The Scheduled Maintenance services listed in bold type must be done at the times or mileages specified to ensure the continued proper functioning of the emission control system. These, and all other maintenance services in- cluded in this manual, should be done to provide best vehicle performance and reliability.
Page 430 • Change your engine oil more often if you drive your vehicle off-road for an extended period of time. • Under no circumstances should oil change intervals exceed 6,000 mi (10,000 km) or 6 months, whichever comes first. Your dealer will reset the oil change indicator message after completing the scheduled oil change.
Page 431 430 MAINTENANCE SCHEDULES At Each Oil Change • Change the engine oil filter. • Inspect the brake hoses and lines. • Check the manual transmission fluid level. CAUTION! Failure to perform the required maintenance items may result in damage to the vehicle.
Page 432 Required Maintenance Intervals Maintenance Items Change the engine oil and engine oil filter. Rotate tires. If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter, replace if necessary. Inspect the brake linings, replace if necessary. Replace the air conditioning filter.
Page 433 432 MAINTENANCE SCHEDULES Maintenance Items Inspect the front suspension, tie rod ends and boot seals, replace if necessary. Replace the engine air cleaner filter. Change the manual transmission fluid if using your vehicle for any of the following: trailer towing, snow plowing, heavy loading, taxi, police, delivery service (commercial service), off-road, desert operation or more then 50% of your driving is at sustained high...
Page 434 Maintenance Items Change the transfer case fluid if using your vehicle for any of the following: police, taxi, fleet, off-road or fre- quent trailer towing. Inspect and replace PCV valve if necessary. Flush and replace the engine coolant. Replace the ignition cables. Replace the spark plugs.
Page 435 434 MAINTENANCE SCHEDULES WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
Page 436: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......437 Prepare For The Appointment .
Page 437 436 IF YOU NEED CONSUMER ASSISTANCE Publication Order Forms ....441 Department Of Transportation Uniform Tire Quality Grades ......442 Treadwear .
Page 438: Suggestions For Obtaining Service For Your Vehicle
SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty.
Page 439: Daimlerchrysler Motors Corporation
438 IF YOU NEED CONSUMER ASSISTANCE special tools, and the latest information to ensure your vehicle is fixed correctly and in a timely manner. This is why you should always talk to your authorized dealer’s service manager first. Most matters can be re- solved with this process.
Page 440: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its Customer Center. Any hearing or speech impaired customer, who has access to a TDD or a conventional teletypewriter (TTY) in the United States, can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 441: Warranty Information (U.s. Vehicles Only)
440 IF YOU NEED CONSUMER ASSISTANCE WARNING! Engine exhaust, some of its constituents, and certain vehicle components contain, or emit, chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain prod- ucts of component wear contain, or emit, chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 442: In Canada
To contact NHTSA, you may either call the Auto Safety Hotline toll free at 1–888–327–4236 (TTY: 1–800–424– 9153), or go to http://www.safercar.gov; or write to: Administrator, NHTSA, 400 Seventh Street, SW., Wash- ington, D.C. 20590. You can also obtain other information about motor vehicle...
Page 443: Quality Grades
442 IF YOU NEED CONSUMER ASSISTANCE • Diagnostic Procedure Manuals Diagnostic Procedure Manuals are filled with dia- grams, charts and detailed illustrations. These practi- cal manuals make it easy for students and technicians to find and fix problems on computer-controlled ve- hicle systems and features.
Page 444: Traction Grades
All passenger car tires must conform to Federal safety requirements in addition to these grades. Treadwear The treadwear grade is a comparative rating, based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear 1-1/2 times as well on the government course as a tire graded 100.
Page 445: Temperature Grades
444 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat, when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 446 INDEX...
Page 447 446 INDEX ABS (Anti-Lock Brake System) ... . 208,309 Adding Fuel ......340 Adding Washer Fluid .
Page 448 Axle Lock ......290,291 Battery ....... 389 Emergency Starting .
Page 449 448 INDEX Charging System Light ....206 Chart, Tire Sizing ......314 Check Engine Light (Malfunction Indicator Light) .
Page 450 Defroster, Windshield ....260,262 Delay (Intermittent) Wipers ....100 Diagnostic System, Onboard .
Page 451 450 INDEX Jacking ......366 Jump Starting ......371 Tow Hooks .
Page 452 Engine Oil ......385 Finish Care ......407 Flashers Hazard Warning .
Page 453 452 INDEX Gasoline/Oxygenate Blends ....337 Gauges Coolant Temperature ....209 Fuel .
Page 454 Key ....... . . 12 Ignition Key Removal ..... 12 Illuminated Entry .
Page 455 454 INDEX Back-Up ......422 Brake Assist Warning ....115,214 Brake Warning .
Page 456 Tires ....... 317 Locking Axle ......290,291 Locks Door .
Page 457 456 INDEX Trip ......210,211 Off-Pavement Driving (Off-Road) ... . 294 Off-Road Driving (Off-Pavement) .
Page 458 Pregnant Women and Seat Belts ....50 Preparation for Jacking ....367 Pretensioners Seat Belts .
Page 459 458 INDEX Restraints, Child ..... . . 62,67 Restraints, Occupant ..... . 40 Roll Over Warning .
Page 460 Sentry Key Programming ....16 Sentry Key Replacement ....16 Service Assistance .
Page 461 460 INDEX Storage, Vehicle ..... . 266,419 Storing Your Vehicle ..... . 419 Sunrider .
Page 462 Spare Tire ......367 Spinning ......325 Tread Wear Indicators .
Page 463 462 INDEX Trip Computer ......215 Trip Odometer ......211 Trip Odometer Reset Button .
Page 464 INDEX 463 Windshield Washers ....100,393 Fluid ....... 393 Windshield Wiper Blades .
Page 465 INTRODUCTION INTRODUCTION ROLLOVER WARNING HOW TO USE THIS MANUAL WARNINGS AND CAUTIONS VEHICLE IDENTIFICATION NUMBER VEHICLE MODIFICATIONS/ALTERATIONS THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Ignition Key RemovalKey-In-Ignition ReminderSTEERING WHEEL LOCK To Manually Lock the Steering WheelTo Release the Steering Wheel LockSENTRY KEY Replacement KeysCustomer Key ProgrammingGeneral InformationSECURITY ALARM SYSTEM - IF EQUIPPED To Set the AlarmTo Disarm the SystemILLUMINATED ENTRY REMOTE KEYLESS ENTRY - IF EQUIPPED To Unlock the Doors and Swing GateTo Lock the Doors and Swing GateUsing The Panic AlarmTo Turn Off Flash Lights With Lock Programming Additional TransmittersGeneral InformationBattery ReplacementREMOTE STARTING SYSTEM - IF EQUIPPED DOORS Upper Half Door Window Removal (If Equipped)Upper Half Door Window Installation (If Equipped)Front Door RemovalRear Door Removal (Four-Door Models)DOOR LOCKS Manual Door LocksPower Door Locks - If EquippedAutomatic Unlock Doors On ExitAutomatic Door LocksWINDOWS Power Windows - If EquippedRear Power Windows (Four-Door Models Only)Wind BuffetingREAR SWING GATE...
Page 466 81-326-0855 Printed in U.S.A. Second Edition...

Jeep 2008 Wrangler Owner's Manual

Wrangler

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

What to Do in Emergencies

Maintaining Your Vehicle

Quick Links

Chapters

Related Manuals for Jeep 2008 Wrangler

Summary of Contents for Jeep 2008 Wrangler
