Assigning a mixed step value using the wheels
Example: assign step 2 at 30% to Golden Scan's color wheel parameter (p2).
Keypresses
1. Select spots.
2. Press the SK for the parameter
selection.
3. Press [STEP UP] or [STEP
DOWN] to reach step 2
4. Move the wheel until 2.3 is
reached.
Or
Keypresses
1. Select spots.
2. Press the SK for parameter
selection.
3. Press and hold {SHIFT]
4. Press SK 2
5. Move the wheel until 2.3 is
reached.
Parameter mode assignments for Cyberlight and
Intellabeam
Certain parameters of Intellabeam and Cyberlight have multiple operation modes (such as
a color wheel which can have a half color, rotation, etc.). Modes are represented by an
additional icon displayed after the parameter value. Access to the parameter modes is
through SKs after parameter selection.
These parameters are:
•
Static gobo (p6) - Cyberlight and Intellabeam.
•
Shutter (p 8) - Cyberlight and Intellabeam.
•
Rotating gobo (p13) - Cyberlight only.
•
Color wheel - (p 14 for Cyberlight; p2 for Intellabeam)
When you select one of these special parameters on the SKs, the operation modes are
displayed on the on the Controller display in PARAM mode. Press the operation mode that
you want and continue as usual.
Spot Parameters
Results/Comments
The controller SK display shows the
parameter selections. If you do not see the
parameter display, press [PARAM].
The parameter value for p2 shows
Results/Comments
The controller SK display shows the
parameter selections. If you do not see the
parameter display, press [PARAM].
The SK display shows the corresponding
steps.
The parameter value for p2 shows
6-11
2.3
.
2.3
.
