Compulite Spark User Manual page 227

Assigning a default space
You can also assign DMX output address by entering a default space. The Default Space
option assigns the selected default space to all spots per selected connector; therefore you
can only use this if all of the spots output from the connector have the same DMX offset.
Keypresses
1. Press F1 DMX Address
2. Press F1 Default Space
3. Select the number of DMX
channels that will be allocated
to each spot.
4. Select the connector
assignment.
Or
Keypresses
1. Press F1 DMX Address
2. Press F2 Select Spot
3. Enter the spot numbers on the
keypad.
4. Select the connector.
5. Enter the first DMX address
that you will use for spots.
6. Press F1 Default Space
7. Select the number of DMX
channels that will be allocated
to each spot.
8. Press F1 Store
The Mix Output Menu
Results/Comments
You are prompted to enter the default
output length.
Each spot is assigned a DMX output
address according to the default offset.
Results/Comments
Spark prompts for a beginning address.
You are prompted to enter the default
output length.
The DMX addresses appear under the spot
numbers.
21-7
Spark
