20-10 The Channel Patch

Enabling General master control

Dimmers that were removed from General Master control can be re-instated
Keypresses
1. Press F1 General Master
2. Enter the dimmer number.
3. Press F4 Enable G.M.

Examining soft patch assignments

You can isolate individual channels, dimmer, and scroller patch assignments for
examination.
The result of a channel exam might look like this:
DIM- 7 107
CH/SCR 107 107
% CH FL FL
CURVE 2 2
The result of a dimmer exam might look like this:
Dimmer...................107
DMX/connector... ....107
Proportional.............FL
Curve........................2
Channel..................107
Scroller.......................
G.M....................Active
Example: Examine the soft patch assignments for channel 100.
Keypresses
1. Press F1 Exam
2. Press F1 Channel
3. Enter the number 100 on the
numeric keypad.
4. Press F1 Exam
5. Press [+] or [F1] and [–] or
[F2] to view the next or
previous channel.
Spark
Results/Comments
The system prompts for the dimmer number.
More than one dimmer can be selected.
The selected dimmer/s are displayed in black and
are fully responsive to changes in the General
Master level.
2077
107
FL
2
Free Status
DMX1
Linear
Results/Comments
You are prompted for the channel number.
The dimmers patched to channel 100 are
displayed.
