Overview

Overview
Memories can be divided into 9 parts, part 0 through part 8. Each part can consist of a
group of spots, spot parameters, and/or channels. Each part can be assigned its own time-
in or wait- in time.
You may assign all spot parameters or selected parameters to a part. For example, the
gobo parameter of a spot may be assigned to a part, causing it to change after the rest of
the spot's parameters have changed. A spot, parameter, or channel can be assigned to only
one part.
Spots and channels can be assigned to Parts while programming a memory or an existing
memory can be divided into Parts.
Intensity and spot parameters, assigned to different parts, appear in different colors. To
view the color code for parts, press [PART] when the editor is idle.
Part # Color
0 no color
1 light green
2 light gray
3 dark blue
4 brown
5 light cyan
6 light violet
7 cyan
8 orange

Part Qs display

Channel intensity and spot parameter values that are assigned to Parts are appear on the
Stage display according to the color code above.
Parts and their time assignments are displayed in the Memory List.
Examining a selected memory shows the color coded Parts and their time assignments at
the bottom of the display.
In the XFade Exam a crossfade to a Part Q is dynamically displayed.
