Compulite Spark User Manual page 234

21-14 The Mix Output Menu
Example: A Profile Zoom is mounted on a yoke. A conventional dimmer controls the
lamp, while the yoke is associated with the X/Y and focus parameters of a moving light.
Yoke # DMX address
5 1
6 7
Step 1 (if necessary)- Defining a yoke
Keypresses
1. Press F2 Select Device
2. Place the cursor on the space you
have reserved for the yoke definition.
3. Press F5 Define Device
4. Type: Yoke, Yo,
5. Use the procedure described above
to define the x and y parameters.
6. Move the cursor to parameter DM .
7. Type 99
8. Define the rest of the parameters
9. Press F1 Store
Step 2 -Assigning spot numbers
The next step is to patch the unit to a spot number.
Keypresses
1. Press F2 Select Device
2. Use the arrow keys (F2 and F3) to
place the cursor on your selection.
3. Press F4 Select Spot #
4. Using our example, press 5 on the
numeric keypad.
5. Press F2 Thru Spot # or [
the console.
6. Using our example, press 6 on the
numeric keypad.
7. Press F1 Store
Spark
Dimmer Control Channel
100 100
101 101
Results/Comments
Access the device list.
Select the Define Device option.
Identify yoke as a new device.
Identifies this parameter as an external
dimmer.
Values for "home" and clear functions
may also be entered at this time.
Results/Comments
Access the device list for selection.
Select "yoke".
Æ Æ
Assign a device to a range of spot
] on
numbers.
Spot numbers 5 and 6 control yokes.
