14-8

Erasing a Library

Erasing a Library
Spot parameters with library assignments retain the parameter value when the library is
erased. Example: Erase Gobo library 9.
Keypresses
1. Press [GOBO]
2. Select 9 on the numeric
keypad.
3. Press [ERASE]
4. Press [ERASE]

Programming a Delta with Libraries

A Delta for applying libraries may be programmed. The example below shows how to
program a Delta that is used to assign Position library 1 to the selected spots. The spots
must, of course, be part of the library.
Keypresses
1. Select one or more spots.
2. Press [POSITION]
3. Enter 1 on the keypad.
4. Press [=]
5. Press [DELTA]
6. Press [STORE]
Spark
Results/Comments
Spark asks: Are You Sure???
The message: Library G-09 Erased is displayed.
Results/Comments
When the Delta is applied to a memory, Position
library 1 is assigned to the selected spots.
