Example: Return channels .55
Keypresses
1. Press F3 Default (1 to 1)
2. Press F2 Channels
3. Enter 55 on the numeric
keypad.
4. Press F1 Thru Channel
and enter 57 on the keypad
or Æ Æ
Press [ ] and enter 57 on
the keypad.
5. Press F3 Store

Examining DMX input assignments

Isolate selected input channels for examination.
Keypresses
1. Press F5 Exam
2. Enter the input number on
the numeric keypad.
3. Press F1 Enter
4. Press or F1 Previous or
F2 Next or [-] [+] to
continuing.

Assigning macros to DMX input

One macro can be assigned to an input channel.
When a macro is assigned, raising the intensity level of the input channel operates the
macro. The default execution threshold is 50%. The execution threshold can be changed in
the Assign Input option in the Macro menu.
Keypresses
1. Go to the Macro menu.
2. Press F5 Assign Input
3. Enter a macro number.
4. Enter an input channel.
5. Optional - Press F2 Start
From and enter a level.
6. Press F1 Store
Æ
57 to the default
Results/Comments
Spark prompts for a channel number.
The selected channels return to default.
Results/Comments
Spark prompts: Exam assignment of input #:
The patch assignments for the selected input
channel are displayed.
Results/Comments
The input patch table is displayed.
Spark prompts for an Input channel number.
The default level assignment is 50%.
The DMX Input patch 24-5
