Assigning frame values

Frames can be assigned using the numeric keypad or parameter wheel 2. If you use the
wheel to assign frame values, it is not necessary to press [FRAME].
When using the numeric keypad:
If the system is configured for at least 10 frames, you must enter frame 1 as 01.
If the system is configured for at least 20 frames, you must enter frame 2 as 02.
If the system is configured for at least 30 frames, you must enter frame 3 as 03.
Partial frames can also be entered on the numeric keypad. Examples: [FRAME] [1] [•]
[6] or [FRAME] [11] [•] [8].
In the example below channel 5 is the control channel. Assign frame 11.
Keypresses
1. Select channel 5.
2. Optional–assign intensity.
3. Press [FRAME]
4. Enter 11 on the numeric
keypad.
5. To assign a different frame
value, press [FRAME] again
and select a frame number.
¾ ¾
Note
Instead of step 5 [+] and [-] can be used to go to the next or previous scroller frame.

Releasing a scroller from a memory

Scrollers can be released from memories. After releasing a scroller from a memory, frame
values will be determined by the tracking. Releasing a scroller must be done via memory
modification.
Keypresses
1. Select the memory for
modification.
2. Select the scroller channel.
3. Press [FRAME]
4. Press [ERASE] or [RELEASE]
5. Press [STORE]
Selecting and Editing Scrollers
Results/Comments
The frame value is displayed in green,
meaning that the scroller is selected in the
editor and is ready for a value assignment. If
intensity is assigned the channel number is
displayed in red. If no intensity is assigned
only the 's' denoting scroller is displayed in
red.
Results/Comments
Channels that have both intensity and frame
assignments appear in dark blue. Channels
that have only scroller frame assignments
appear in white. The frame values appear in
green.
You now have access to the scroller.
The frame is released from the memory.
