Example: Assign 73% intensity to channel 5.
Keypresses
1. Press [CHANNEL]
2. Select 5 on the numeric
keypad.
3. Press [@].
4. Press [7] [•] [3]
If the system is defined as
USA, press [7] and [3].

Repeating an intensity assignment

You can repeat the last intensity assignment.
Example: assign 33% to channel 1 and repeat the level assignment to the next channel you
select. In the example below the intensity on channel 1 is repeated for channel 8.
Keypresses
1. Select channel 1.
2. Assign intensity level at 33%
using the dimmer wheel.
3. Select channel 8.
4. Press [•] (dot)

Releasing a Channel from the Editor

Select channels and remove them from the editor. The channel/s can be bumped out or
faded out.
Keypresses
1. Select the channel.
2. Press [RELEASE]
Keypresses
1. Select the channel.
2. Press [ERASE]
Releasing a Channel from the Editor
Results/Comments
Skip this step if the numeric selection default
is channel
Int appears in the command line after the
channel selection and channel 5 is displayed
in red.
73 is displayed under the channel number on
the channel display.
Results/Comments
You can also assign the level on the numeric
keypad.
33% intensity is assigned to channel 8.
Results/Comments
The channel faders down. When it reaches
0% it is released from the editor.
Results/Comments
The channel bumps out.
5-5
Spark
