11-4

Freeing assignments

Fade to the assignment in selected fade time
Example: Assign memory 1 to the free fader in an 8 second fade.
Keypresses
1. Select memory 1.
2. Press [TIME]
3. Press [8] on the
numeric keypad.
4. Press [GO TO]

Assigning editor groups

You can assign the channels and spots in the editor to A or B. The LED display shows grp
when the assignment is the editor group. All the channels and spots in the editor are
assigned.
Only manual fading can be used with Grp assignments.
Keypresses
1. Channels/spots and
assign values.
2. Press [A] or [B]
Freeing assignments
When an assignment is freed, the output of the spots and channels in the assignment blacks
out. If they are active in the editor or on a controller their output bumps to the level
determined in that assignment.
Example: Free the assignment from A.
Keypresses
1. Press [FREE]
2. Press [A]
3. Press [B]
4. Press [CLEAR] to
exit Free mode
¾ ¾
Note
[SEQ] is disabled when the memory assignment on either A or B is freed.
[SEQ] and [AUTO] are disabled when the assignments from both A and B are freed.
Spark
Results/Comments
The selected memory is faded to the active fader. The
fade rate is according to the time selected. [SEQ] and
[AUTO] function are automatically enabled; the LED
for [SEQ] is on and the Auto Assign Led is on.
Results/Comments
Grp is displayed in the LED window for A or B.
Results/Comments
The message Assign Key Expected is displayed.
The assignment is released. The channels and spots
released from A blackout or if they are active in the
editor or on a controller output at the level of that
assignment. The console is still in Free mode; Free is
still displayed in the command line.
The console is still in Free mode; Free is still displayed
in the command line.
