Assigning a range of memories to sequential
controllers
Example: assign memories 30 - 35 to controllers 6 - 11.
Keypresses
1. Select memories 30
2.
Press [ASSIGN
3. Press controller 6's SK.
Assigning an unspecified range of memories to
sequential controllers
Example: Assign memory 17 to controller 7, memory 18 to controller 8, memory 19 to
controller 9, until all the available controllers have been assigned.
Keypresses
1. Select Memory 17 as the
starting memory.
Æ Æ
2. Press [ ]
3.
Press [ASSIGN]
4. Press the controller 7's SK.

Assigning masks

Use Mask to assign the channels and spots in a memory as a group assignment.
Example: Assign the channels and spots in memory 1 as a group assignment to controller
7.
Keypresses
1. Press [MASK]
2. Enter 1 on the numeric
keypad.
3.
Press [ASSIGN]
4. Press the controller 7's SK.
Results/Comments
Æ
35.
The message Assign Key Expected is displayed.
Memory 30 is assigned to controller 6, memory
31 to controller 7, etc.
Results/Comments
It is unnecessary to select the last memory in
the range, as this cannot exceed the number
of controllers.
The message Assign Key Expected is
displayed.
Memory 17 is assigned to controller 7,
memory 18 to controller 8, and so on finishing
with memory 30 assigned to controller 20.
Results/Comments
The message Assign Key Expected is
displayed.
The assignment is recognized as a group. Grp
appears on the controller display.
Assigning Memories 12-5
