5.2
Figure 5-2 Mailbox Bin
Number Administration
Screen
Bin Number/Bin Attempts - This field determines the number of times to
attempt to reach a subscriber from a pre-defined bin. For the bin number,
enter a number from 01 to 09. Then enter 1 - 9 to determine the number of
attempts from that bin. At least one (1) attempt must be entered.
Override Status - This field is used both to indicate and to change the status
of the override schedule. A one (1) in this field indicates the override schedule
is on for this schedule. A zero (0) indicates that the override schedule is off.

Mailbox Bin Number Administration Screen

The Mailbox Bin Numbers Administration Screen is used to program the phone
numbers used by mailboxes that are allowed to make Outcalls.
There are four fields that need to be programmed for each bin number entry. Each
time an entry is saved, Emerald ICE HD Voicemail will numerically sort all the
existing entries.
The mailbox bin screen uses a multi-page format. All bin entries for the same
mailbox are listed together on these pages. Emerald ICE HD Voicemail comes
default with two pages of entries.
When this two-page limit has been reached, additional pages may be added by
following these steps:
5
1. Press to save the second page
3
2. Press to clear the screen - this starts a new page of entries
3. Add additional bin entries as required
Emerald ICE HD Voicemail Installation Manual
5-3
