Tadiran Telecom Emerald ICE Installation Manual page 144

13-10
Emerald ICE HD Voicemail Installation Manual
Loopback Test Mailbox - A test mailbox, located at each network node, where
messages can be sent to test network communications.
Box Length - The number of digits in a valid mailbox number for the network
node being established.
Mailbox Range - The range of mailbox numbers (from / to) for the network
node being established.
Full Duplex - This field is not used at this time.
Non-Priority Message - The delivery schedules for Non-Priority Messages
sent by NORMAL USERS (user type 0) and PRIORITY USERS (user type 1)
are defined in the From, To and Delay areas of these fields. This field value
was defined in the AMIS Network User Type field on the Class of Service
Screen. Refer to section 7 - Class of Service Administration.
From/To fields - The times that the local Emerald ICE HD Voicemail system will
attempt to transmit each type of queued messages to the network node being
established. Times must be entered in 24-hour format.
Delay - The number of seconds that the local Emerald ICE HD Voicemail system
will wait before again attempting to send a message to the network node
being established after a failed attempt. The default is three attempts. (Note
that this setting overrides the setting defined in the Delay Between Attempts
field on the Outdial Parameters Screen).
Priority Message - The delivery schedules for Priority Messages sent by
NORMAL USERS and PRIORITY USERS are defined in the From, To and
Delay areas of these fields. (Note that the normal or priority message type was
previously defined on the COS Screen).
Programming Steps
Based on the information defined in the Networking Data sheet, a network node is
established by performing the steps below:
a. From the Main Status Menu, press 8 for "Network." The Network Node
Administration screen will be displayed.
b. Enter the required information into the Network Node Setup fields using
the Networking Data sheet as a guide. When finished entering the data,
5
press then Y to save the record.
E
c. Press to return to the Main Status Menu. Press
to the Status Screen
E
again to return
