15-2
Emerald ICE HD Voicemail Installation Manual
FUNCTION KEY MAPPING
Most versions of Procomm Plus have only the first four function(F) keys mapped
to terminal functions. Since ICE HD Voicemail uses all 12 Function keys, you may
need to map the keys from
can be programmed. You only need to program the NORMAL state. These
settings are found under the Setup option, Terminal Setup, Keyboard files.
The complete set of correct key mappings is below:
1
. . . . . . . . . . . ^A@^M
2
. . . . . . . . . . . ^AA^M
3
. . . . . . . . . . . ^AB^M
4
. . . . . . . . . . . ^AC^M
5
. . . . . . . . . . . ^AD^M
6
. . . . . . . . . . . ^AE^M
7
. . . . . . . . . . . ^AF^M
8
. . . . . . . . . . . ^AG^M
9
. . . . . . . . . . . ^AH^M
0
. . . . . . . . . . . ^AI^M
!
. . . . . . . . . . . ^AJ^M
@
. . . . . . . . . . . ^AK^M
Once you have made these changes, save them and exit to the terminal screen.
!
Press the key and the screen should refresh. If the system has been idle for
five minutes or more the screen saver has activated. Press the
!
the key to view the screens and begin programming.
5 @
to manually. Each F key has four states that
M
bar and then
