1. Remove the 4 mounting screws from the CCB card and replace with the 4
standoffs supplied with the Emerald ICE HD Voicemail System card. Set the
4 mounting screws aside.
2. While holding the card close to the Emerald ICE cabinet connect the ribbon
cable with the receptacle on the CCB card and connect the red/white
power line connector with the receptacle on the 610-2 board.
3. Line up the 4 mounting holes on Simlicity for ICE Voice Mail System card
with the 4 stand offs on the CCB card. Firmly, secure the Emerald ICE HD
Voicemail card to the CCB card with the 4 mounting screws previously set
aside.
4. Turn the Emerald ICE cabinet power on and verify that the Voice Mail card
green System Status LED's at the top of the card is blinking.
5. Connect a 9-pin serial cable male-end to the female receptacle on the
Emerald ICE Flash Voice Mail System card.
6. Connect the other end of the serial cable with the desired serial port on a
laptop or PC.
The Emerald ICE HD Voicemail System is now installed, synchronized and ready for
programming on a laptop or PC. The card automatically starts up once it is
inserted and receives power from the Emerald ICE bus.
As Emerald ICE HD Voicemail boots up, you will see a series of screens open and
close as the various drivers and programs load. Finally the port status screen will
appear. Emerald ICE HD Voicemail is now installed and running.
All that is left is to program the user mailboxes and voice menu options. Refer to
Sections 3 through 7 for detailed instructions on Emerald ICE HD Voicemail system
programming.
The figure below shows the various ports and indicator lights located on the
Emerald ICE HD Voicemail card.
