3.2
Figure 3-1 Main Status
Screen

Main Status Screen

The Main Status Screen displays the current status of the active system ports,
allows entrance to the system programming menus and allows the running of the
clean up routine manually.
The lower section of the screen displays current statistical information about
Emerald ICE HD Voicemail.
Keystrokes Available from the Main Status Screen
The following function keys may be used at the Main Status Screen:
1
. . . . . . brings up the Enter Password window. (The default password of 0000
may be changed.)
2
. . . . . . toggles the screen saver on and off
3
. . . . . manually starts the Disk Cleanup process
9
. . . . . . prompts for a "Channel Number to Start"
0
. . . . . prompts for a "Channel Number to Stop"
Emerald ICE HD Voicemail Installation Manual
3-3
