16.6
16-4
Emerald ICE HD Voicemail Installation Manual
7. Make note of the drive letter assigned to the device.
Step 3 - enter the backup job parameters;
1. Type CD \UTILS and press the e key.
2. Type the required Backup command as follows, then press the
key:
USAGE:
BP-BACK [drive] [directory] (i.e. BP-BACK E smithco) where: [directory] is
the directory name where to store the data, up to eight characters in length.
DO NOT include a backslash or drive letter as part of the directory name.
[drive] this is the drive letter assigned to the storage unit when the GUEST
program is run. DO NOT include any characters other than the actual drive
letter. i.e. E not E:
The Backup procedure will now start and run to completion without any further
user input. Backup time will vary depending on the number of messages in the
system.

Imation Superdisk LS-120

External Drive
Step 1 - Exit the ICE HD Voicemail system to DOS:
1
1. Press at the Status screen and enter the system password (default is
1234).
2. Press 8 for System Shutdown.
1
3. Press either
Step 2 -Activate the device:
1. Connect the SuperDisk drive cable to the 25 pin parallel port connector
located on the front of the card.
2. Connect the power cord to the SuperDisk drive - the power light should
come on.
3. Insert the desired SuperDisk disk into the drive.
4. Type CD \IMATION and press the e key.
0
or as desired
R
