4.2.1.1 UPS status icons.
The various icons showing the status of the UPS are:
Animated synoptic: An animated synoptic gives a global overview of the UPS current operating mode.
This synoptic is available on all On-Line UPS.
The synoptic drawing depends on the UPS topology. The different drawings are described in the table below.
Note: In case of loss of communication with the UPS, all the elements of the synoptic are grey.
Network Management Card
Normal operation
Alarm present. This icon links directly to the
alarm page.
Loss of communication with the UPS
UPS with automatic bypass
UPS with automatic and manual bypass
UPS without automatic bypass
