Notified Applications - Eaton Network Management Card User Manual

4.4.3

Notified Applications

Click on Notified Applications in the menu.
This menu enables:
The addition of the supervision stations receiving traps and configuration of the trap type.
To list all the Notified Applications and the main parameters.
To test the operation of notified applications
by simulating power loss
by sending a real shutdown sequence.
Up to 100 destinations can be managed by the card:
35 in TCP connected mode or
100 in UDP not connected mode or
mixed mode: 20 connected and 50 not connected.
Important note: It is not necessary to add the Intelligent Power Protector protecting your servers in this list. These
modules subscribe and unsubscribe themselves automatically.
Select an entry in the list to modify the values in the edit zone at the bottom of the page. The table displays the
following information:
All: selects all the lines.
Nr: the index where the application is stored into the table.
Hostname or Address IP: By priority, the hostname of the computer is displayed when the IP address can be
Network Management Card Page
– User Manual 34003991XT_EN/EF 54/127
