6.3.5

Trap receivers menu

This menu is used to view or modify the applications receiving traps and to configure trap type.
------------------------------------------------------------------------
NETWORK MANAGEMENT CARD
Trap receiver
------------------------------------------------------------------------
1 : Receiver 1
2 : Receiver 2
3 : Receiver 3
0 : Exit
------------------------------------------------------------------------
------------------------------------------------------------------------
NETWORK MANAGEMENT CARD
Trap receiver X
------------------------------------------------------------------------
1 : Hostname or IP address [166.99.224.68]
2 : Application mane [MyTrap]
3 : Trap community [ ]
4 : Protocol (Disabled, V1, V3, V1V3) [Disabled]
5 : MIB filter (b0=Pulsar, bit1=Power MIB, bit2=IETF) [2]
0 : Exit
----------------------------------------------------------------------
(1) Only the 3 less significant bits are used (b0 to b2). The possible value are from 0 to 7 (3 bits used set to 1).
6.3.6

System menu

This menu is used to view or modify the system settings.
Network Management Card
– User Manual 34003991XT_EN/EF
(1)
