Eaton Network Management Card User Manual page 47

in CSV format
ω
Periodic report: In addition to the e-mails sent when events occur, a periodic e-mail
containing the 3 log files (or 4 when the optional Sensor is connected) can be sent
to the recipient every x days at the time specified by the user.
To configure the first transmission, specify the day, time and frequency of the next
transmission in the "next report" box. After this date, the page will show the date
and time of the next transmission.
Data are sent in CSV format.
ω
Save: Saves any modifications.
Test: enables an e-mail to be sent to the recipient immediately. This is one way of checking e-mail transmission,
particularly access to the SMTP server configured in "Network" settings. A transmission report is added to the
system log.
The event label in the subject and text of the message is replaced with a test label.
If the user makes any modifications to the page, they must be saved before using the "Test" function.
Notified events:
The right side of the page shows the events that can be notified.
By default, only the main events of battery operation and a few UPS alarms are accessible. All the events appear
if the Show/Hide Events option is actuated.
By default, two events are selected for notification. The user can modify this pre-selection by ticking other events
or can, on the contrary, restore the initial configuration by clicking Set Default.
Email Message Settings: access to the message configuration page
Network Settings: enables the name of the SMTP server to be entered.
Network Management Card
– User Manual 34003991XT_EN/EF
See page
Page
47/127
