1.3.4

Administration

NEW features:
Secured management through SNMP V3
Support of dual stack IPv4 / IPv6
Up to 35 workstations (in TCP connected mode) or up to 100(in UDP broadcasted mode) protected by Intelligent Power
Protector - Central or local configuration.
Up to 5 browsers connected at the same time (3 in SSL).
Minimum recommended browser versions: Internet Explorer 8, Mozilla Firefox 3.6, Chrome.
E-mail sending configurable according to UPS alarms and transmission of a periodical report.
Control of UPS on/off switching via the HTML interface.
Adjustment and control of PowerShare outlets via the HTML interface, sequential starting of the installation and optimisation
of backup time by shutting down non-priority systems.
Automatic data and time adjustment via NTP server.
Protection by encrypted password.
Protection by secure SSL connection.
Backup logs in the non-volatile memory.
Languages available: English / French/ Spanish / German / Italian / Chinese Traditional / Chinese Simplified / Japanese /
Portuguese / Russian / Korean / Czech.
On-line help in English available for each page.
Card firmware update via the network.
Card Mass settings via the network with Intelligent Power Manager.
Firmware Mass Upgrade via the network with Intelligent Power Manager.
1.3.5

Network

Fast ETHERNET 10/100 Mbits compatibility with auto-negotiation on the RJ45 outlet.
Compatible with 1Gbits networks in 100 Mbits mode
1.3.5.1 List of ports used
Protocol
SSH
TELNET
SMTP
HTML
NTP
BootP, DHCP
SNMP V1 & V3
TRAP SNMP
SSL
NSM in connected mode
NSM in UDP broadcast mode
1.3.6

Environment sensor

Temperature measurement from 0 to 70 °C with +/- 1 °C accuracy.
Network Management Card
Direction
in
in
out
out
in/out
in/out
in/out
in/out
out
in/out
in/out
– User Manual 34003991XT_EN/EF
Type Port Number
TCP 22
TCP 23
TCP 25
TCP 80
UDP 68, 67
UDP 68, 67
UDP 161
UDP 162
TCP 443
TCP 5000
UDP 4679, 4680
