converted into a hostname by a DNS server or if the application has been entered as a hostname.
Application Name: Given by the application at subscription time.
Output: number of the UPS output from which the client is powered.
Configuration: shows where the parameters of the Intelligent Power Protector come from: Local (coming from
the application) or Central (coming from the card).
The Central shutdown configuration is available by clicking on the Configuration link.
Shutdown duration: the shutdown duration necessary to properly shutdown the computer.
Shutdown after: the time available to the user from the power failure until the launch of the shutoff sequence of
the UPS and equipment. This parameter is optional.
Connected: This value is set to YES if the notified application connects through TCP protocol.
Many actions are available on this page:
Remove: Depending on the kind of application, the selected ones will definitively disappear from the table as
SNMP applications, or they will disappear and automatically re-subscribe as Intelligent Power Protector
applications.
Utility failure Test: Two alarms, 'Utility failure' and 'Utility restored' spaced 60 seconds apart, will be sent to the
applications selected, making sure that the applications can be reached over the network.
Shutdown Test: This test simulates a UPS low battery sequence. It enables an easy check to see if the server
protection works correctly.
- No intervention on the UPS is required.
- The applications selected will process the simultaneous alarms and perform an actual shutdown sequence.
WARNING!
- This test will generate a REAL shutdown sequence of the selected servers on which the Intelligent Power
Protector application is running.
Add NMS: allows an SNMP trap receiver to be added such as a Network Management System.
Modify NMS: allows an SNMP trap receiver to be modified.
Both buttons open a new window where it is possible to enter the Application name, the Hostname or IP Address,
the protocol version needed: V1, V3 or both, the Trap community (only used in V1) and the filter on the several
implemented MIBs.
