7.2.2

Choice 2: Modify IPv4 Network settings

Enables the modification of network parameters
For each of the following questions, you can press <Return> to select the
value
shown in braces, or you can enter a new value.
Should this target obtain IP settings from the network?[N]
Static IP address [xxx.xxx.xxx.xxx]?
Subnet Mask [xxx.xxx.xxx.xxx]?
Gateway IP address [xxx.xxx.xxx.xxx]?
Wait during your new configuration is saved ...
Reset the card to take into account the new configuration.
In DHCP mode, the card can receive the following parameters according to the DHCP server settings
IPv4 address
Subnet Mask
IPv4 Gateway address
Primary DNS server
Secondary DNS server
The card must be restarted
7.2.3

Choice 3: Set Ethernet speed

Enables the modification of the network speed
Set the Ethernet speed : [1 : Automatic, 2 : 10 MBit]
1
New Ethernet speed : Automatic
Wait during the new setting is saved ...
Reset the card to take into account the new configuration.
The card must be restarted
Network Management Card
in order for the new parameters to be taken into account.
in order for the new parameters to be taken into account.
– User Manual 34003991XT_EN/EF
