upsEnvironmentInput1Closed
upsEnvironmentInput1Open
upsEnvironmentInput2Open
upsEnvironmentInput2Closed
The level is used to select traps to be sent to the supervisor. This adjustment is available from the "Notified
applications" page
8.2.4
EATON Powerware MIB
The Card implements the full Eaton Powerware MIB (PowerMIB), including alarm tables. The Eaton traps are
sent. The Eaton Powerware MIB access path is 1.3.6.1.4.1.534.
Table is an abbreviated list of objects from the PowerMIB. The UPS output/load segment controls objects and the
entire MIB description is available at http://powerquality.eaton.com/Support/SoftwareDrivers.
MIB Object
xupsIdentManufacturer
xupsIdentModel
xupsIdentSoftwareVersion
xupsIdentOemCode
xupsBatTimeRemaining
xupsBatVoltage
xupsBatCurrent
xupsBatCapacity
xupsBatteryAbmStatus
xupsBatteryLastReplacedDate
xupsInputFrequency
xupsInputLineBads
xupsInputNumPhases
xupsInputTable
xupsInputPhase
xupsInputVoltage
xupsInputCurrent
xupsInputWatts
xupsInputSource
xupsDualInputStatus
xupsSecondaryInputWatch
Network Management Card
– User Manual
34003991XT_EN/EF
Trap 61
Level 2
Trap 62
Level 2
Trap 64
Level 2
Trap 63
Level 2
SNMP Format
Add.path
String
{1.1.0}
String
{1.2.0}
String
{1.3.0}
Integer
{1.4.0}
Seconds
{2.1.0}
Volts DC
{2.2.0}
Amps DC
{2.3.0}
Percent
{2.4.0}
Integer
{2.5.0}
String
{2.6.0}
0.1 Hertz
{3.1.0}
Integer
{3.2.0}
Integer
{3.3.0}
{3.4.0}
Integer
{3.4.1.1.x}
RMS Volts
{3.4.1.2.x}
RMS Amps
{3.4.1.3.x}
Watts
{3.4.1.4.x}
Integer
{3.5.0}
Integer
{3.6.0}
Integer
{3.7.0}
Page
121/127
