Installation In The Ups - Eaton Network Management Card User Manual

Ethernet Port
LED Colour Activity
Off
ACT Green
On
Flashing
Off
100M Orange
On
Settings/Sensor Port
LED Colour Activity
Off
UPS Green
On
Data
Flashing
Off
RS232 Orange
On
Flashing

2.3 Installation in the UPS

The Network Management Card (Network-MS) is "hot-swappable". It can be installed in all UPSs of the EATON
Pulsar series or EATON Powerware series equipped with a Minislot without having to shut it down.
On the UPS, remove the cover from the Minislot
Note the card's MAC address
Insert and tighten the card's retaining screws
Connect the ETHERNET cable
Wait 2 min. the card is completely operational when the green UPS Data LED flashes continuously
Network Management Card
Description
Card not connected to the network.
Card connected to the network but without activity
Port is active in receiving / transmission
Port operating at 10Mbits/s.
Port operating at 100Mbits/s.
Description
Card startup in progress.
Communication with UPS in progress
Normal operation. Communication with the UPS is operational
Configuration menu is active
Normal operation. Configuration menu is deactived
Communication with the Environment Sensor (option).
– User Manual 34003991XT_EN/EF
Page
18/127
