Rear Tear Position

You can adjust the rear tear position for forms loaded in the rear paper path from
-390 to +30 (where each unit is 0.176 mm [1/144 in.]). The default value is 0.
To change or check the Rear Tear Position:
1. Press MENU.
2. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
3. Press ENTER.
4. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
5. Press ENTER to display the current value.
6. Press SCROLL/MICRO or SCROLL/MICRO until the desired value for Rear
7. Press ENTER.
8. Press START or RETURN to exit the Menu. See "Exiting the configuration

Rear Left Margin Alignment

This parameter adjusts the distance of the first print position to the left margin
from 0 to 60 units (where each unit is 0.706 mm [1/36 in.]). The default is 0 units.
The total range of adjustment is 42.36 mm (1.66 in.).
To change or check the Rear Left Margin Alignment:
1. Press MENU.
2. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
3. Press ENTER.
4. Press SCROLL/MICRO or SCROLL/MICRO until the printer displays
5. Press ENTER to display the current value.
6. Press SCROLL/MICRO or SCROLL/MICRO until the desired value for Rear
7. Press ENTER.
8. Press START or RETURN to exit the Menu. See "Exiting the configuration
CONFIGURATION MENU
Printer Adjustments
Printer Adjustments
Rear Tear Position
Tear Position is displayed.
An asterisk (*) will be displayed in front of the selected value.
menu" on page 39.
CONFIGURATION MENU
Printer Adjustments
Printer Adjustments
Rear Left Margin Align
Left Margin Align is displayed.
An asterisk (*) will be displayed in front of the selected value.
menu" on page 39.
Chapter 9. Printer Adjustments
123
